| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_185T04_9000002548_17226cztM0_level2.evt | modeM0/AS1A05_185T04_9000002548_17226cztM0_level2_quad_clean.evt |
| Size (bytes) | 446,071,680 | 92,162,880 |
| Size | 425.4 MB | 87.9 MB |
| Events in quadrant A | 3,038,615 | 599,171 |
| Events in quadrant B | 3,210,537 | 607,338 |
| Events in quadrant C | 3,583,671 | 570,363 |
| Events in quadrant D | 3,237,821 | 564,032 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13293 | 3 |
| B | 0 | 13642 | 2 |
| C | 0 | 14893 | 2 |
| D | 0 | 14165 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6449 | 24 | 0.372151% |
| B | 6449 | 47 | 0.728795% |
| C | 6449 | 123 | 1.907272% |
| D | 6449 | 67 | 1.038921% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7609 | 6450 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7609 | 6450 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7609 | 6450 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7609 | 6450 | 32 | 32 | 0.42% | 0.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7163 | 39.92 | 788 | 771 | 160.1 |
| A | 12 | 194 | 5719 | 30.9 | 788 | 771 | 160.1 |
| A | 3 | 137 | 5551 | 29.85 | 788 | 771 | 160.1 |
| B | 0 | 219 | 33232 | 215.78 | 793 | 772 | 150.4 |
| B | 0 | 189 | 31577 | 204.78 | 793 | 772 | 150.4 |
| B | 0 | 244 | 20281 | 129.69 | 793 | 772 | 150.4 |
| C | 3 | 233 | 500417 | 2808.84 | 760 | 767 | 177.9 |
| C | 14 | 238 | 117869 | 658.3 | 760 | 767 | 177.9 |
| C | 13 | 61 | 5474 | 26.46 | 760 | 767 | 177.9 |
| D | 10 | 70 | 164336 | 871.84 | 769 | 745 | 187.6 |
| D | 1 | 52 | 72534 | 382.59 | 769 | 745 | 187.6 |
| D | 13 | 189 | 34779 | 181.38 | 769 | 745 | 187.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
