| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_185T04_9000002552_17248cztM0_level2.evt | modeM0/AS1A05_185T04_9000002552_17248cztM0_level2_quad_clean.evt |
| Size (bytes) | 430,122,240 | 88,246,080 |
| Size | 410.2 MB | 84.2 MB |
| Events in quadrant A | 3,108,538 | 568,953 |
| Events in quadrant B | 3,156,696 | 569,290 |
| Events in quadrant C | 3,089,867 | 540,193 |
| Events in quadrant D | 3,225,703 | 537,135 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13465 | 1 |
| B | 0 | 13491 | 1 |
| C | 0 | 13352 | 1 |
| D | 0 | 14006 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6560 | 51 | 0.777439% |
| B | 6560 | 56 | 0.853659% |
| C | 6560 | 67 | 1.021341% |
| D | 6559 | 85 | 1.295929% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7485 | 6561 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7485 | 6561 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7485 | 6561 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7484 | 6560 | 38 | 38 | 0.51% | 0.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 23 | 26749 | 160.91 | 798 | 779 | 161.4 |
| A | 15 | 174 | 12166 | 70.55 | 798 | 779 | 161.4 |
| A | 0 | 226 | 8596 | 48.43 | 798 | 779 | 161.4 |
| B | 6 | 36 | 22380 | 141.44 | 792 | 772 | 152.8 |
| B | 12 | 111 | 18057 | 113.15 | 792 | 772 | 152.8 |
| B | 11 | 111 | 15711 | 97.79 | 792 | 772 | 152.8 |
| C | 14 | 238 | 118260 | 659.63 | 755 | 758 | 178.1 |
| C | 3 | 233 | 29057 | 158.86 | 755 | 758 | 178.1 |
| C | 13 | 61 | 5349 | 25.77 | 755 | 758 | 178.1 |
| D | 10 | 70 | 235947 | 1253.09 | 769 | 748 | 187.7 |
| D | 13 | 189 | 33292 | 173.39 | 769 | 748 | 187.7 |
| D | 2 | 234 | 28308 | 146.83 | 769 | 748 | 187.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
