| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_185T04_9000002552_17256cztM0_level2.evt | modeM0/AS1A05_185T04_9000002552_17256cztM0_level2_quad_clean.evt |
| Size (bytes) | 458,582,400 | 95,817,600 |
| Size | 437.3 MB | 91.4 MB |
| Events in quadrant A | 3,317,035 | 620,103 |
| Events in quadrant B | 3,422,807 | 624,676 |
| Events in quadrant C | 3,329,228 | 592,239 |
| Events in quadrant D | 3,354,808 | 588,624 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14226 | 2 |
| B | 0 | 14728 | 2 |
| C | 0 | 14322 | 2 |
| D | 0 | 14792 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6834 | 40 | 0.585309% |
| B | 6835 | 111 | 1.623994% |
| C | 6834 | 105 | 1.536435% |
| D | 6834 | 55 | 0.804800% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8809 | 6836 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8810 | 6837 | 14 | 14 | 0.16% | 0.20% |  |
| C | 8809 | 6836 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8809 | 6836 | 25 | 25 | 0.28% | 0.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 23 | 121917 | 725.26 | 826 | 808 | 167.0 |
| A | 0 | 226 | 14689 | 83.13 | 826 | 808 | 167.0 |
| A | 15 | 174 | 10092 | 55.6 | 826 | 808 | 167.0 |
| B | 7 | 220 | 53123 | 334.21 | 826 | 806 | 156.5 |
| B | 0 | 197 | 40425 | 253.1 | 826 | 806 | 156.5 |
| B | 0 | 189 | 37775 | 236.17 | 826 | 806 | 156.5 |
| C | 14 | 238 | 122096 | 651.61 | 795 | 799 | 186.2 |
| C | 3 | 233 | 103170 | 549.94 | 795 | 799 | 186.2 |
| C | 13 | 61 | 5639 | 26.0 | 795 | 799 | 186.2 |
| D | 10 | 70 | 118813 | 603.75 | 805 | 783 | 195.5 |
| D | 13 | 189 | 109052 | 553.82 | 805 | 783 | 195.5 |
| D | 2 | 152 | 38524 | 193.05 | 805 | 783 | 195.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
