| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_010T02_9000002556_17290cztM0_level2.evt | modeM0/AS1A05_010T02_9000002556_17290cztM0_level2_quad_clean.evt |
| Size (bytes) | 654,583,680 | 114,192,000 |
| Size | 624.3 MB | 108.9 MB |
| Events in quadrant A | 4,527,410 | 706,839 |
| Events in quadrant B | 4,578,732 | 707,728 |
| Events in quadrant C | 4,577,984 | 676,910 |
| Events in quadrant D | 5,458,055 | 670,065 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20509 | 3 |
| B | 0 | 20486 | 3 |
| C | 0 | 20501 | 3 |
| D | 0 | 23310 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 206 | 0 |
| B | 0 | 206 | 0 |
| C | 0 | 206 | 0 |
| D | 0 | 206 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10045 | 87 | 0.866103% |
| B | 10045 | 126 | 1.254355% |
| C | 10046 | 158 | 1.572765% |
| D | 10046 | 206 | 2.050567% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 11040 | 10048 | 0 | 0 | 0.00% | 0.00% |  |
| B | 11040 | 10048 | 0 | 0 | 0.00% | 0.00% |  |
| C | 11041 | 10049 | 0 | 0 | 0.00% | 0.00% |  |
| D | 11041 | 10049 | 71 | 71 | 0.64% | 0.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 10379 | 38.63 | 1173 | 1150 | 238.9 |
| A | 4 | 2 | 9682 | 35.71 | 1173 | 1150 | 238.9 |
| A | 3 | 137 | 9307 | 34.14 | 1173 | 1150 | 238.9 |
| B | 12 | 111 | 28193 | 119.04 | 1170 | 1138 | 227.3 |
| B | 11 | 111 | 24925 | 104.66 | 1170 | 1138 | 227.3 |
| B | 14 | 111 | 21824 | 91.02 | 1170 | 1138 | 227.3 |
| C | 14 | 238 | 171378 | 641.6 | 1125 | 1131 | 265.3 |
| C | 3 | 233 | 19889 | 70.69 | 1125 | 1131 | 265.3 |
| C | 13 | 61 | 7851 | 25.33 | 1125 | 1131 | 265.3 |
| D | 13 | 232 | 762861 | 2760.14 | 1135 | 1104 | 276.0 |
| D | 11 | 176 | 201107 | 724.69 | 1135 | 1104 | 276.0 |
| D | 1 | 52 | 96529 | 345.76 | 1135 | 1104 | 276.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
