| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_010T02_9000002556_17299cztM0_level2.evt | modeM0/AS1A05_010T02_9000002556_17299cztM0_level2_quad_clean.evt |
| Size (bytes) | 449,029,440 | 90,912,960 |
| Size | 428.2 MB | 86.7 MB |
| Events in quadrant A | 3,139,112 | 591,306 |
| Events in quadrant B | 3,197,364 | 596,440 |
| Events in quadrant C | 3,099,175 | 556,066 |
| Events in quadrant D | 3,713,248 | 547,659 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13766 | 2 |
| B | 0 | 13928 | 2 |
| C | 0 | 13553 | 2 |
| D | 0 | 15572 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6616 | 24 | 0.362757% |
| B | 6616 | 33 | 0.498791% |
| C | 6615 | 45 | 0.680272% |
| D | 6615 | 87 | 1.315193% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7601 | 6617 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7601 | 6617 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7600 | 6616 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7600 | 6616 | 59 | 59 | 0.78% | 0.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 235 | 71350 | 439.87 | 791 | 774 | 160.4 |
| A | 4 | 2 | 28612 | 173.5 | 791 | 774 | 160.4 |
| A | 0 | 226 | 6770 | 37.37 | 791 | 774 | 160.4 |
| B | 0 | 230 | 47201 | 304.38 | 794 | 773 | 152.5 |
| B | 12 | 111 | 18389 | 115.49 | 794 | 773 | 152.5 |
| B | 11 | 111 | 15747 | 98.17 | 794 | 773 | 152.5 |
| C | 14 | 238 | 117276 | 662.01 | 753 | 759 | 176.0 |
| C | 3 | 233 | 31865 | 176.73 | 753 | 759 | 176.0 |
| C | 8 | 128 | 8622 | 44.67 | 753 | 759 | 176.0 |
| D | 13 | 232 | 410846 | 2242.09 | 755 | 733 | 182.9 |
| D | 11 | 176 | 170908 | 930.35 | 755 | 733 | 182.9 |
| D | 5 | 222 | 133450 | 725.56 | 755 | 733 | 182.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
