| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_010T02_9000002556_17320cztM0_level2.evt | modeM0/AS1A05_010T02_9000002556_17320cztM0_level2_quad_clean.evt |
| Size (bytes) | 442,448,640 | 67,633,920 |
| Size | 422.0 MB | 64.5 MB |
| Events in quadrant A | 3,196,594 | 400,301 |
| Events in quadrant B | 3,247,185 | 399,927 |
| Events in quadrant C | 3,274,034 | 384,198 |
| Events in quadrant D | 3,213,844 | 383,875 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14061 | 2 |
| B | 0 | 14135 | 2 |
| C | 0 | 14228 | 2 |
| D | 0 | 14370 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6886 | 47 | 0.682544% |
| B | 6886 | 56 | 0.813244% |
| C | 6886 | 86 | 1.248911% |
| D | 6886 | 57 | 0.827766% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7781 | 6887 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7781 | 6887 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7781 | 6887 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7781 | 6887 | 15 | 15 | 0.19% | 0.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7261 | 38.25 | 831 | 813 | 168.6 |
| A | 3 | 137 | 6488 | 33.66 | 831 | 813 | 168.6 |
| A | 12 | 194 | 5953 | 30.49 | 831 | 813 | 168.6 |
| B | 12 | 111 | 19498 | 116.42 | 827 | 805 | 160.6 |
| B | 11 | 111 | 17302 | 102.74 | 827 | 805 | 160.6 |
| B | 14 | 111 | 15291 | 90.22 | 827 | 805 | 160.6 |
| C | 14 | 238 | 121963 | 643.06 | 799 | 801 | 188.4 |
| C | 5 | 112 | 33724 | 174.74 | 799 | 801 | 188.4 |
| C | 3 | 233 | 6333 | 29.36 | 799 | 801 | 188.4 |
| D | 2 | 152 | 43929 | 222.45 | 806 | 782 | 194.0 |
| D | 9 | 65 | 39347 | 198.83 | 806 | 782 | 194.0 |
| D | 1 | 52 | 33853 | 170.5 | 806 | 782 | 194.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
