| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_032T01_9000002564_17368cztM0_level2.evt | modeM0/AS1T03_032T01_9000002564_17368cztM0_level2_quad_clean.evt |
| Size (bytes) | 523,149,120 | 65,787,840 |
| Size | 498.9 MB | 62.7 MB |
| Events in quadrant A | 3,428,926 | 399,506 |
| Events in quadrant B | 3,454,656 | 401,426 |
| Events in quadrant C | 3,498,768 | 382,251 |
| Events in quadrant D | 5,034,220 | 368,912 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14191 | 2 |
| B | 0 | 14230 | 2 |
| C | 0 | 14516 | 2 |
| D | 0 | 19287 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6299 | 110 | 1.746309% |
| B | 6299 | 112 | 1.778060% |
| C | 6299 | 131 | 2.079695% |
| D | 6299 | 342 | 5.429433% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7594 | 6299 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7594 | 6299 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7594 | 6300 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7594 | 6299 | 165 | 165 | 2.17% | 2.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7862 | 39.42 | 892 | 876 | 177.2 |
| A | 12 | 194 | 6461 | 31.52 | 892 | 876 | 177.2 |
| A | 3 | 137 | 6074 | 29.33 | 892 | 876 | 177.2 |
| B | 12 | 111 | 18557 | 108.06 | 880 | 861 | 163.8 |
| B | 11 | 111 | 16287 | 94.2 | 880 | 861 | 163.8 |
| B | 14 | 111 | 14173 | 81.29 | 880 | 861 | 163.8 |
| C | 14 | 238 | 132829 | 681.6 | 846 | 857 | 193.6 |
| C | 3 | 233 | 45043 | 228.21 | 846 | 857 | 193.6 |
| C | 0 | 79 | 13440 | 64.99 | 846 | 857 | 193.6 |
| D | 13 | 232 | 1164472 | 5709.37 | 849 | 828 | 203.8 |
| D | 5 | 222 | 191766 | 936.83 | 849 | 828 | 203.8 |
| D | 1 | 52 | 188179 | 919.23 | 849 | 828 | 203.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
