| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_066T01_9000002600_17541cztM0_level2.evt | modeM0/AS1T03_066T01_9000002600_17541cztM0_level2_quad_clean.evt |
| Size (bytes) | 408,919,680 | 85,210,560 |
| Size | 390.0 MB | 81.3 MB |
| Events in quadrant A | 3,018,946 | 549,062 |
| Events in quadrant B | 3,122,208 | 560,849 |
| Events in quadrant C | 2,896,791 | 534,069 |
| Events in quadrant D | 2,940,313 | 519,630 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12690 | 1 |
| B | 0 | 12979 | 1 |
| C | 0 | 12212 | 1 |
| D | 0 | 12754 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5964 | 75 | 1.257545% |
| B | 5964 | 73 | 1.224011% |
| C | 5964 | 45 | 0.754527% |
| D | 5964 | 23 | 0.385647% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7199 | 5965 | 39 | 39 | 0.54% | 0.65% |  |
| B | 7199 | 5965 | 24 | 24 | 0.33% | 0.40% |  |
| C | 7199 | 5965 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7199 | 5965 | 8 | 8 | 0.11% | 0.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 237 | 194406 | 1319.42 | 734 | 722 | 146.8 |
| A | 0 | 226 | 6386 | 38.58 | 734 | 722 | 146.8 |
| A | 12 | 194 | 5437 | 32.12 | 734 | 722 | 146.8 |
| B | 15 | 222 | 121917 | 883.39 | 730 | 713 | 137.2 |
| B | 10 | 245 | 90387 | 653.58 | 730 | 713 | 137.2 |
| B | 0 | 182 | 31684 | 225.73 | 730 | 713 | 137.2 |
| C | 14 | 238 | 110403 | 679.11 | 699 | 704 | 161.5 |
| C | 3 | 233 | 57047 | 348.8 | 699 | 704 | 161.5 |
| C | 13 | 61 | 5099 | 27.21 | 699 | 704 | 161.5 |
| D | 5 | 222 | 176853 | 1022.69 | 709 | 686 | 172.3 |
| D | 7 | 238 | 41349 | 236.06 | 709 | 686 | 172.3 |
| D | 13 | 189 | 25931 | 146.55 | 709 | 686 | 172.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
