| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_056T01_9000002604_17575cztM0_level2.evt | modeM0/AS1A05_056T01_9000002604_17575cztM0_level2_quad_clean.evt |
| Size (bytes) | 578,021,760 | 91,123,200 |
| Size | 551.2 MB | 86.9 MB |
| Events in quadrant A | 5,797,785 | 532,180 |
| Events in quadrant B | 3,740,790 | 584,181 |
| Events in quadrant C | 3,812,296 | 558,489 |
| Events in quadrant D | 3,643,941 | 561,080 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22036 | 5 |
| B | 0 | 15929 | 2 |
| C | 0 | 16102 | 2 |
| D | 0 | 15889 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7527 | 1023 | 13.591072% |
| B | 7527 | 269 | 3.573801% |
| C | 7527 | 297 | 3.945795% |
| D | 7527 | 172 | 2.285107% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9056 | 7526 | 665 | 665 | 7.34% | 8.84% |  |
| B | 9057 | 7527 | 0 | 0 | 0.00% | 0.00% |  |
| C | 9057 | 7529 | 2 | 2 | 0.02% | 0.03% |  |
| D | 9057 | 7528 | 3 | 3 | 0.03% | 0.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 237 | 2309766 | 12485.55 | 907 | 886 | 184.9 |
| A | 0 | 226 | 7852 | 37.67 | 907 | 886 | 184.9 |
| A | 3 | 137 | 6947 | 32.78 | 907 | 886 | 184.9 |
| B | 0 | 230 | 24763 | 129.36 | 943 | 917 | 184.3 |
| B | 12 | 111 | 22625 | 117.76 | 943 | 917 | 184.3 |
| B | 11 | 111 | 19337 | 99.92 | 943 | 917 | 184.3 |
| C | 14 | 238 | 137733 | 643.92 | 903 | 908 | 212.5 |
| C | 3 | 233 | 116710 | 544.99 | 903 | 908 | 212.5 |
| C | 0 | 207 | 36254 | 166.34 | 903 | 908 | 212.5 |
| D | 13 | 189 | 62105 | 273.97 | 927 | 898 | 223.4 |
| D | 5 | 222 | 34444 | 150.15 | 927 | 898 | 223.4 |
| D | 2 | 234 | 27651 | 119.75 | 927 | 898 | 223.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
