| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_042T01_9000002630_17735cztM0_level2.evt | modeM0/AS1T03_042T01_9000002630_17735cztM0_level2_quad_clean.evt |
| Size (bytes) | 449,953,920 | 93,594,240 |
| Size | 429.1 MB | 89.3 MB |
| Events in quadrant A | 3,277,939 | 591,106 |
| Events in quadrant B | 3,246,187 | 608,051 |
| Events in quadrant C | 3,248,536 | 579,731 |
| Events in quadrant D | 3,382,023 | 571,705 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14558 | 1 |
| B | 0 | 14332 | 1 |
| C | 0 | 14266 | 1 |
| D | 0 | 14829 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6936 | 196 | 2.825836% |
| B | 6937 | 162 | 2.335303% |
| C | 6937 | 188 | 2.710105% |
| D | 6937 | 129 | 1.859593% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7076 | 6937 | 28 | 28 | 0.40% | 0.40% |  |
| B | 7077 | 6938 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7077 | 6938 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7077 | 6938 | 11 | 11 | 0.16% | 0.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 122174 | 719.96 | 821 | 800 | 168.6 |
| A | 0 | 226 | 7165 | 37.76 | 821 | 800 | 168.6 |
| A | 3 | 137 | 6301 | 32.63 | 821 | 800 | 168.6 |
| B | 12 | 111 | 19180 | 115.7 | 819 | 797 | 158.9 |
| B | 0 | 219 | 18179 | 109.4 | 819 | 797 | 158.9 |
| B | 11 | 111 | 16697 | 100.07 | 819 | 797 | 158.9 |
| C | 14 | 238 | 122548 | 657.63 | 783 | 785 | 185.2 |
| C | 3 | 233 | 30247 | 159.12 | 783 | 785 | 185.2 |
| C | 5 | 218 | 17641 | 91.04 | 783 | 785 | 185.2 |
| D | 1 | 52 | 242975 | 1230.49 | 795 | 772 | 196.8 |
| D | 2 | 165 | 48132 | 240.61 | 795 | 772 | 196.8 |
| D | 7 | 238 | 32898 | 163.21 | 795 | 772 | 196.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
