| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_015T01_9000002650_17803cztM0_level2.evt | modeM0/AS1A05_015T01_9000002650_17803cztM0_level2_quad_clean.evt |
| Size (bytes) | 447,612,480 | 109,514,880 |
| Size | 426.9 MB | 104.4 MB |
| Events in quadrant A | 3,032,042 | 725,955 |
| Events in quadrant B | 3,152,156 | 756,923 |
| Events in quadrant C | 3,212,153 | 718,889 |
| Events in quadrant D | 3,747,108 | 690,947 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12938 | 2 |
| B | 0 | 13214 | 2 |
| C | 0 | 13288 | 2 |
| D | 0 | 15222 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6071 | 28 | 0.461209% |
| B | 6071 | 52 | 0.856531% |
| C | 6071 | 74 | 1.218910% |
| D | 6071 | 209 | 3.442596% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7441 | 6072 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7441 | 6072 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7441 | 6072 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7441 | 6072 | 159 | 159 | 2.14% | 2.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 10566 | 62.52 | 785 | 772 | 156.7 |
| A | 0 | 226 | 6946 | 39.41 | 785 | 772 | 156.7 |
| A | 12 | 194 | 5524 | 30.33 | 785 | 772 | 156.7 |
| B | 0 | 230 | 20132 | 131.21 | 797 | 781 | 147.5 |
| B | 12 | 111 | 17020 | 110.11 | 797 | 781 | 147.5 |
| B | 11 | 111 | 14616 | 93.81 | 797 | 781 | 147.5 |
| C | 14 | 238 | 122087 | 683.21 | 766 | 772 | 177.6 |
| C | 5 | 218 | 53449 | 296.66 | 766 | 772 | 177.6 |
| C | 3 | 233 | 45445 | 251.59 | 766 | 772 | 177.6 |
| D | 7 | 238 | 683151 | 3853.98 | 747 | 730 | 177.1 |
| D | 7 | 38 | 128685 | 722.63 | 747 | 730 | 177.1 |
| D | 2 | 120 | 32804 | 181.14 | 747 | 730 | 177.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
