| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_085T01_9000002658_17864cztM0_level2.evt | modeM0/AS1A05_085T01_9000002658_17864cztM0_level2_quad_clean.evt |
| Size (bytes) | 526,080,960 | 94,392,000 |
| Size | 501.7 MB | 90.0 MB |
| Events in quadrant A | 3,143,372 | 612,390 |
| Events in quadrant B | 3,204,183 | 619,628 |
| Events in quadrant C | 3,239,068 | 592,088 |
| Events in quadrant D | 5,883,829 | 560,129 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13866 | 2 |
| B | 0 | 13935 | 2 |
| C | 0 | 13891 | 2 |
| D | 0 | 22240 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6811 | 17 | 0.249596% |
| B | 6811 | 27 | 0.396418% |
| C | 6811 | 59 | 0.866246% |
| D | 6811 | 927 | 13.610336% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7666 | 6812 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7666 | 6812 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7666 | 6812 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7666 | 6811 | 762 | 762 | 9.94% | 11.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 16701 | 96.72 | 814 | 798 | 164.4 |
| A | 0 | 226 | 7080 | 38.2 | 814 | 798 | 164.4 |
| A | 3 | 137 | 6276 | 33.31 | 814 | 798 | 164.4 |
| B | 12 | 111 | 19003 | 116.63 | 817 | 797 | 156.1 |
| B | 11 | 111 | 16316 | 99.42 | 817 | 797 | 156.1 |
| B | 14 | 111 | 14119 | 85.34 | 817 | 797 | 156.1 |
| C | 14 | 238 | 122536 | 660.1 | 786 | 793 | 184.4 |
| C | 5 | 218 | 40531 | 215.46 | 786 | 793 | 184.4 |
| C | 13 | 61 | 5526 | 25.66 | 786 | 793 | 184.4 |
| D | 7 | 238 | 2882798 | 15920.16 | 744 | 727 | 181.0 |
| D | 1 | 52 | 147101 | 808.55 | 744 | 727 | 181.0 |
| D | 2 | 234 | 28317 | 152.4 | 744 | 727 | 181.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
