| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_075T01_9000002660_17875cztM0_level2.evt | modeM0/AS1T03_075T01_9000002660_17875cztM0_level2_quad_clean.evt |
| Size (bytes) | 213,770,880 | 42,520,320 |
| Size | 203.9 MB | 40.6 MB |
| Events in quadrant A | 1,556,952 | 270,822 |
| Events in quadrant B | 1,609,498 | 280,099 |
| Events in quadrant C | 1,581,049 | 266,505 |
| Events in quadrant D | 1,526,215 | 261,536 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 60 | 0 |
| B | 0 | 60 | 0 |
| C | 0 | 60 | 0 |
| D | 0 | 60 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6440 | 2 |
| B | 0 | 6648 | 1 |
| C | 0 | 6546 | 1 |
| D | 0 | 6463 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2920 | 33 | 1.130137% |
| B | 2920 | 49 | 1.678082% |
| C | 2920 | 66 | 2.260274% |
| D | 2920 | 23 | 0.787671% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4300 | 2921 | 0 | 0 | 0.00% | 0.00% |  |
| B | 4300 | 2921 | 1 | 1 | 0.02% | 0.03% |  |
| C | 4300 | 2921 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4300 | 2921 | 2 | 2 | 0.05% | 0.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 237 | 9982 | 116.67 | 401 | 394 | 82.2 |
| A | 4 | 2 | 4624 | 51.47 | 401 | 394 | 82.2 |
| A | 0 | 226 | 3410 | 36.7 | 401 | 394 | 82.2 |
| B | 0 | 197 | 10794 | 136.55 | 401 | 392 | 76.2 |
| B | 12 | 111 | 9075 | 113.98 | 401 | 392 | 76.2 |
| B | 11 | 111 | 7645 | 95.21 | 401 | 392 | 76.2 |
| C | 14 | 238 | 60721 | 658.32 | 387 | 390 | 91.6 |
| C | 3 | 233 | 7932 | 82.29 | 387 | 390 | 91.6 |
| C | 13 | 61 | 2706 | 25.27 | 387 | 390 | 91.6 |
| D | 7 | 238 | 28972 | 271.8 | 387 | 380 | 105.2 |
| D | 2 | 234 | 11286 | 103.67 | 387 | 380 | 105.2 |
| D | 10 | 199 | 7754 | 70.1 | 387 | 380 | 105.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
