| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_025T01_9000002670_17921cztM0_level2.evt | modeM0/AS1T03_025T01_9000002670_17921cztM0_level2_quad_clean.evt |
| Size (bytes) | 316,776,960 | 55,379,520 |
| Size | 302.1 MB | 52.8 MB |
| Events in quadrant A | 1,964,264 | 351,405 |
| Events in quadrant B | 3,106,746 | 351,715 |
| Events in quadrant C | 2,034,455 | 347,996 |
| Events in quadrant D | 2,210,918 | 338,949 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 82 | 0 |
| B | 0 | 82 | 0 |
| C | 0 | 82 | 0 |
| D | 0 | 82 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8638 | 1 |
| B | 0 | 11894 | 1 |
| C | 0 | 8730 | 1 |
| D | 0 | 9441 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4068 | 41 | 1.007866% |
| B | 4068 | 317 | 7.792527% |
| C | 4068 | 67 | 1.647001% |
| D | 4068 | 51 | 1.253687% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5243 | 4069 | 18 | 18 | 0.34% | 0.44% |  |
| B | 5243 | 4069 | 235 | 235 | 4.48% | 5.78% |  |
| C | 5243 | 4069 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5243 | 4069 | 45 | 45 | 0.86% | 1.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 88702 | 900.63 | 484 | 473 | 98.0 |
| A | 4 | 2 | 8630 | 83.27 | 484 | 473 | 98.0 |
| A | 10 | 228 | 4519 | 41.3 | 484 | 473 | 98.0 |
| B | 15 | 222 | 1165107 | 12737.03 | 483 | 471 | 91.4 |
| B | 0 | 189 | 25862 | 277.69 | 483 | 471 | 91.4 |
| B | 12 | 111 | 10791 | 112.86 | 483 | 471 | 91.4 |
| C | 3 | 233 | 137094 | 1255.97 | 466 | 469 | 108.8 |
| C | 14 | 238 | 73512 | 671.47 | 466 | 469 | 108.8 |
| C | 13 | 61 | 3351 | 26.49 | 466 | 469 | 108.8 |
| D | 7 | 238 | 319247 | 2786.68 | 468 | 454 | 114.4 |
| D | 12 | 110 | 52898 | 458.43 | 468 | 454 | 114.4 |
| D | 10 | 70 | 23291 | 199.63 | 468 | 454 | 114.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
