| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_025T01_9000002670_17925cztM0_level2.evt | modeM0/AS1T03_025T01_9000002670_17925cztM0_level2_quad_clean.evt |
| Size (bytes) | 489,450,240 | 118,241,280 |
| Size | 466.8 MB | 112.8 MB |
| Events in quadrant A | 3,423,624 | 769,000 |
| Events in quadrant B | 3,523,580 | 788,848 |
| Events in quadrant C | 3,487,750 | 753,325 |
| Events in quadrant D | 3,867,368 | 737,287 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15668 | 2 |
| B | 0 | 15737 | 2 |
| C | 0 | 15716 | 2 |
| D | 0 | 17236 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7670 | 89 | 1.160365% |
| B | 7671 | 99 | 1.290575% |
| C | 7671 | 111 | 1.447008% |
| D | 7671 | 109 | 1.420936% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8316 | 7673 | 1 | 1 | 0.01% | 0.01% |  |
| B | 8317 | 7674 | 2 | 2 | 0.02% | 0.03% |  |
| C | 8317 | 7674 | 2 | 2 | 0.02% | 0.03% |  |
| D | 8317 | 7674 | 46 | 46 | 0.55% | 0.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 25160 | 134.6 | 884 | 866 | 180.5 |
| A | 0 | 226 | 7639 | 37.52 | 884 | 866 | 180.5 |
| A | 3 | 137 | 6821 | 32.99 | 884 | 866 | 180.5 |
| B | 12 | 111 | 20669 | 115.25 | 889 | 865 | 171.8 |
| B | 11 | 111 | 17923 | 99.27 | 889 | 865 | 171.8 |
| B | 0 | 189 | 17513 | 96.89 | 889 | 865 | 171.8 |
| C | 14 | 238 | 132762 | 660.05 | 849 | 851 | 199.8 |
| C | 3 | 233 | 19661 | 94.12 | 849 | 851 | 199.8 |
| C | 9 | 160 | 16670 | 79.15 | 849 | 851 | 199.8 |
| D | 10 | 70 | 239027 | 1147.19 | 851 | 823 | 207.6 |
| D | 1 | 52 | 125104 | 598.54 | 851 | 823 | 207.6 |
| D | 7 | 238 | 114020 | 545.16 | 851 | 823 | 207.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
