| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_019T01_9000002672_17964cztM0_level2.evt | modeM0/AS1A05_019T01_9000002672_17964cztM0_level2_quad_clean.evt |
| Size (bytes) | 431,988,480 | 90,316,800 |
| Size | 412.0 MB | 86.1 MB |
| Events in quadrant A | 3,104,756 | 586,991 |
| Events in quadrant B | 3,218,007 | 592,298 |
| Events in quadrant C | 3,106,920 | 564,008 |
| Events in quadrant D | 3,228,985 | 556,409 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13279 | 1 |
| B | 0 | 13494 | 1 |
| C | 0 | 13061 | 1 |
| D | 0 | 13651 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6243 | 58 | 0.929041% |
| B | 6243 | 84 | 1.345507% |
| C | 6242 | 90 | 1.441846% |
| D | 6243 | 93 | 1.489668% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7473 | 6244 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7473 | 6244 | 6 | 6 | 0.08% | 0.10% |  |
| C | 7473 | 6244 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7473 | 6244 | 30 | 30 | 0.40% | 0.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 237 | 55056 | 341.27 | 787 | 770 | 159.1 |
| A | 15 | 174 | 16845 | 101.05 | 787 | 770 | 159.1 |
| A | 4 | 2 | 8940 | 51.36 | 787 | 770 | 159.1 |
| B | 7 | 220 | 61731 | 410.42 | 788 | 771 | 148.5 |
| B | 0 | 197 | 21517 | 139.67 | 788 | 771 | 148.5 |
| B | 5 | 172 | 17786 | 114.55 | 788 | 771 | 148.5 |
| C | 14 | 238 | 117608 | 657.97 | 760 | 765 | 177.6 |
| C | 3 | 233 | 23711 | 129.21 | 760 | 765 | 177.6 |
| C | 13 | 61 | 5429 | 26.26 | 760 | 765 | 177.6 |
| D | 2 | 165 | 80539 | 427.57 | 771 | 751 | 186.6 |
| D | 7 | 238 | 70087 | 371.56 | 771 | 751 | 186.6 |
| D | 13 | 249 | 40924 | 215.28 | 771 | 751 | 186.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
