| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_159T01_9000002678_18001cztM0_level2.evt | modeM0/AS1A05_159T01_9000002678_18001cztM0_level2_quad_clean.evt |
| Size (bytes) | 486,014,400 | 79,709,760 |
| Size | 463.5 MB | 76.0 MB |
| Events in quadrant A | 3,663,339 | 494,414 |
| Events in quadrant B | 3,363,228 | 497,263 |
| Events in quadrant C | 3,421,601 | 481,895 |
| Events in quadrant D | 3,815,198 | 472,069 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15074 | 1 |
| B | 0 | 13954 | 3 |
| C | 0 | 14063 | 1 |
| D | 0 | 15709 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6715 | 69 | 1.027550% |
| B | 6714 | 92 | 1.370271% |
| C | 6715 | 83 | 1.236039% |
| D | 6715 | 101 | 1.504095% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7670 | 6716 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7670 | 6715 | 11 | 11 | 0.14% | 0.16% |  |
| C | 7670 | 6716 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7670 | 6716 | 48 | 48 | 0.63% | 0.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 394531 | 2283.05 | 850 | 835 | 172.4 |
| A | 0 | 226 | 7406 | 38.11 | 850 | 835 | 172.4 |
| A | 3 | 137 | 6453 | 32.58 | 850 | 835 | 172.4 |
| B | 0 | 189 | 37735 | 226.38 | 849 | 832 | 163.0 |
| B | 12 | 111 | 19735 | 115.96 | 849 | 832 | 163.0 |
| B | 11 | 111 | 17081 | 99.68 | 849 | 832 | 163.0 |
| C | 14 | 238 | 125737 | 648.34 | 815 | 822 | 192.7 |
| C | 3 | 233 | 64722 | 331.66 | 815 | 822 | 192.7 |
| C | 0 | 207 | 41332 | 210.26 | 815 | 822 | 192.7 |
| D | 5 | 222 | 372363 | 1683.54 | 815 | 797 | 220.7 |
| D | 11 | 176 | 274005 | 1237.88 | 815 | 797 | 220.7 |
| D | 2 | 234 | 28245 | 124.36 | 815 | 797 | 220.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
