| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_159T01_9000002678_18005cztM0_level2.evt | modeM0/AS1A05_159T01_9000002678_18005cztM0_level2_quad_clean.evt |
| Size (bytes) | 511,833,600 | 113,981,760 |
| Size | 488.1 MB | 108.7 MB |
| Events in quadrant A | 3,512,074 | 779,344 |
| Events in quadrant B | 3,547,776 | 782,308 |
| Events in quadrant C | 3,636,038 | 732,275 |
| Events in quadrant D | 4,382,254 | 723,303 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14465 | 2 |
| B | 0 | 14489 | 2 |
| C | 0 | 14839 | 2 |
| D | 0 | 17014 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6237 | 99 | 1.587302% |
| B | 6237 | 112 | 1.795735% |
| C | 6237 | 152 | 2.437069% |
| D | 6237 | 339 | 5.435305% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7497 | 6237 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7497 | 6237 | 20 | 20 | 0.27% | 0.32% |  |
| C | 7497 | 6238 | 28 | 28 | 0.37% | 0.45% |  |
| D | 7497 | 6238 | 254 | 254 | 3.39% | 4.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 59996 | 333.01 | 889 | 876 | 177.5 |
| A | 4 | 2 | 37985 | 209.03 | 889 | 876 | 177.5 |
| A | 0 | 226 | 7738 | 38.65 | 889 | 876 | 177.5 |
| B | 5 | 172 | 49939 | 295.85 | 874 | 857 | 165.9 |
| B | 0 | 189 | 31818 | 186.62 | 874 | 857 | 165.9 |
| B | 0 | 197 | 31246 | 183.17 | 874 | 857 | 165.9 |
| C | 14 | 238 | 132352 | 691.9 | 826 | 834 | 190.1 |
| C | 3 | 233 | 108727 | 567.61 | 826 | 834 | 190.1 |
| C | 9 | 160 | 70315 | 365.53 | 826 | 834 | 190.1 |
| D | 11 | 176 | 718241 | 3256.0 | 834 | 818 | 220.3 |
| D | 5 | 222 | 247433 | 1119.25 | 834 | 818 | 220.3 |
| D | 7 | 96 | 137764 | 621.52 | 834 | 818 | 220.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
