| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_159T01_9000002678_18009cztM0_level2.evt | modeM0/AS1A05_159T01_9000002678_18009cztM0_level2_quad_clean.evt |
| Size (bytes) | 484,413,120 | 105,007,680 |
| Size | 462.0 MB | 100.1 MB |
| Events in quadrant A | 3,393,671 | 692,986 |
| Events in quadrant B | 3,669,762 | 691,933 |
| Events in quadrant C | 3,549,556 | 662,425 |
| Events in quadrant D | 3,588,289 | 651,488 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14511 | 2 |
| B | 0 | 15204 | 2 |
| C | 0 | 14802 | 2 |
| D | 0 | 15265 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6903 | 89 | 1.289295% |
| B | 6903 | 141 | 2.042590% |
| C | 6903 | 130 | 1.883239% |
| D | 6903 | 76 | 1.100971% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7618 | 6903 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7618 | 6904 | 30 | 30 | 0.39% | 0.43% |  |
| C | 7618 | 6904 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7618 | 6904 | 21 | 21 | 0.28% | 0.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7658 | 37.88 | 880 | 864 | 179.3 |
| A | 3 | 137 | 6399 | 30.86 | 880 | 864 | 179.3 |
| A | 12 | 194 | 6395 | 30.84 | 880 | 864 | 179.3 |
| B | 7 | 220 | 86589 | 502.59 | 875 | 855 | 170.6 |
| B | 0 | 197 | 61350 | 354.63 | 875 | 855 | 170.6 |
| B | 0 | 182 | 34530 | 197.41 | 875 | 855 | 170.6 |
| C | 14 | 238 | 130247 | 654.39 | 835 | 843 | 197.7 |
| C | 0 | 207 | 110563 | 554.85 | 835 | 843 | 197.7 |
| C | 3 | 233 | 44088 | 218.69 | 835 | 843 | 197.7 |
| D | 5 | 222 | 159554 | 749.34 | 854 | 832 | 211.8 |
| D | 11 | 176 | 94854 | 443.89 | 854 | 832 | 211.8 |
| D | 2 | 234 | 30387 | 139.53 | 854 | 832 | 211.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
