| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_159T01_9000002678_18018cztM0_level2.evt | modeM0/AS1A05_159T01_9000002678_18018cztM0_level2_quad_clean.evt |
| Size (bytes) | 481,821,120 | 93,317,760 |
| Size | 459.5 MB | 89.0 MB |
| Events in quadrant A | 3,467,281 | 610,724 |
| Events in quadrant B | 3,461,354 | 615,645 |
| Events in quadrant C | 3,468,409 | 581,431 |
| Events in quadrant D | 3,759,429 | 570,518 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14179 | 2 |
| B | 0 | 14174 | 2 |
| C | 0 | 14078 | 2 |
| D | 0 | 15132 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6418 | 77 | 1.199751% |
| B | 6418 | 81 | 1.262075% |
| C | 6418 | 106 | 1.651605% |
| D | 6418 | 105 | 1.636024% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7578 | 6418 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7578 | 6418 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7578 | 6419 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7578 | 6419 | 42 | 42 | 0.55% | 0.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 54102 | 302.27 | 873 | 860 | 176.1 |
| A | 4 | 2 | 46152 | 257.13 | 873 | 860 | 176.1 |
| A | 15 | 192 | 13179 | 69.94 | 873 | 860 | 176.1 |
| B | 0 | 197 | 26570 | 155.72 | 868 | 848 | 165.2 |
| B | 12 | 111 | 18922 | 109.42 | 868 | 848 | 165.2 |
| B | 11 | 111 | 16193 | 92.9 | 868 | 848 | 165.2 |
| C | 14 | 238 | 129496 | 676.8 | 819 | 830 | 190.1 |
| C | 3 | 233 | 97647 | 509.27 | 819 | 830 | 190.1 |
| C | 0 | 207 | 34681 | 178.06 | 819 | 830 | 190.1 |
| D | 5 | 222 | 291607 | 1422.33 | 835 | 814 | 204.4 |
| D | 11 | 176 | 156259 | 760.32 | 835 | 814 | 204.4 |
| D | 7 | 238 | 111504 | 541.41 | 835 | 814 | 204.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
