| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_159T01_9000002678_18035cztM0_level2.evt | modeM0/AS1A05_159T01_9000002678_18035cztM0_level2_quad_clean.evt |
| Size (bytes) | 554,918,400 | 119,399,040 |
| Size | 529.2 MB | 113.9 MB |
| Events in quadrant A | 4,441,228 | 820,483 |
| Events in quadrant B | 3,470,398 | 834,766 |
| Events in quadrant C | 4,282,515 | 768,298 |
| Events in quadrant D | 4,196,572 | 764,731 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17379 | 1 |
| B | 0 | 14108 | 1 |
| C | 0 | 16889 | 1 |
| D | 0 | 16660 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6124 | 280 | 4.572175% |
| B | 6124 | 134 | 2.188112% |
| C | 6124 | 365 | 5.960157% |
| D | 6123 | 220 | 3.593010% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7404 | 6125 | 173 | 173 | 2.34% | 2.82% |  |
| B | 7404 | 6125 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7404 | 6125 | 123 | 123 | 1.66% | 2.01% |  |
| D | 7403 | 6124 | 101 | 101 | 1.36% | 1.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 982175 | 5608.36 | 870 | 860 | 175.0 |
| A | 15 | 174 | 106817 | 605.56 | 870 | 860 | 175.0 |
| A | 4 | 2 | 14970 | 80.64 | 870 | 860 | 175.0 |
| B | 4 | 48 | 30220 | 180.74 | 859 | 846 | 162.5 |
| B | 0 | 197 | 17867 | 104.73 | 859 | 846 | 162.5 |
| B | 12 | 111 | 17788 | 104.25 | 859 | 846 | 162.5 |
| C | 0 | 207 | 795450 | 4290.38 | 800 | 811 | 185.2 |
| C | 3 | 233 | 149509 | 802.84 | 800 | 811 | 185.2 |
| C | 14 | 238 | 126710 | 679.75 | 800 | 811 | 185.2 |
| D | 7 | 238 | 365614 | 1790.28 | 834 | 814 | 203.8 |
| D | 5 | 222 | 326867 | 1600.13 | 834 | 814 | 203.8 |
| D | 11 | 176 | 232620 | 1137.6 | 834 | 814 | 203.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
