| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_159T01_9000002678_18038cztM0_level2.evt | modeM0/AS1A05_159T01_9000002678_18038cztM0_level2_quad_clean.evt |
| Size (bytes) | 539,619,840 | 105,275,520 |
| Size | 514.6 MB | 100.4 MB |
| Events in quadrant A | 3,457,480 | 701,792 |
| Events in quadrant B | 3,799,212 | 697,821 |
| Events in quadrant C | 3,700,584 | 663,174 |
| Events in quadrant D | 4,913,441 | 640,961 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14685 | 1 |
| B | 0 | 15671 | 1 |
| C | 0 | 15261 | 1 |
| D | 0 | 19354 | 7 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6960 | 44 | 0.632184% |
| B | 6960 | 128 | 1.839080% |
| C | 6960 | 80 | 1.149425% |
| D | 6959 | 320 | 4.598362% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7680 | 6961 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7680 | 6961 | 47 | 47 | 0.61% | 0.68% |  |
| C | 7680 | 6961 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7679 | 6960 | 251 | 251 | 3.27% | 3.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 64208 | 352.88 | 882 | 866 | 179.5 |
| A | 0 | 226 | 7613 | 37.59 | 882 | 866 | 179.5 |
| A | 12 | 194 | 6396 | 30.81 | 882 | 866 | 179.5 |
| B | 7 | 220 | 195254 | 1157.79 | 875 | 859 | 167.9 |
| B | 0 | 197 | 62339 | 366.17 | 875 | 859 | 167.9 |
| B | 5 | 172 | 60131 | 353.02 | 875 | 859 | 167.9 |
| C | 3 | 233 | 195495 | 986.72 | 835 | 843 | 197.3 |
| C | 14 | 238 | 128435 | 646.79 | 835 | 843 | 197.3 |
| C | 8 | 208 | 88667 | 445.19 | 835 | 843 | 197.3 |
| D | 5 | 222 | 685818 | 3291.73 | 841 | 819 | 208.1 |
| D | 7 | 238 | 593046 | 2845.92 | 841 | 819 | 208.1 |
| D | 11 | 176 | 298992 | 1432.86 | 841 | 819 | 208.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
