| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_159T01_9000002678_18041cztM0_level2.evt | modeM0/AS1A05_159T01_9000002678_18041cztM0_level2_quad_clean.evt |
| Size (bytes) | 471,539,520 | 91,163,520 |
| Size | 449.7 MB | 86.9 MB |
| Events in quadrant A | 3,075,091 | 595,767 |
| Events in quadrant B | 3,247,693 | 596,956 |
| Events in quadrant C | 3,317,894 | 569,342 |
| Events in quadrant D | 4,210,257 | 557,112 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13240 | 2 |
| B | 0 | 13715 | 2 |
| C | 0 | 13805 | 2 |
| D | 0 | 16786 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6322 | 28 | 0.442898% |
| B | 6323 | 74 | 1.170331% |
| C | 6323 | 86 | 1.360114% |
| D | 6323 | 146 | 2.309031% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7152 | 6324 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7153 | 6325 | 17 | 17 | 0.24% | 0.27% |  |
| C | 7153 | 6325 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7153 | 6325 | 93 | 93 | 1.30% | 1.47% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 42545 | 258.71 | 789 | 774 | 161.5 |
| A | 0 | 226 | 6828 | 37.5 | 789 | 774 | 161.5 |
| A | 12 | 194 | 5891 | 31.69 | 789 | 774 | 161.5 |
| B | 7 | 220 | 68209 | 440.0 | 785 | 766 | 153.3 |
| B | 15 | 33 | 54100 | 347.95 | 785 | 766 | 153.3 |
| B | 4 | 216 | 20007 | 125.53 | 785 | 766 | 153.3 |
| C | 3 | 233 | 166480 | 937.56 | 752 | 759 | 176.8 |
| C | 14 | 238 | 115326 | 648.16 | 752 | 759 | 176.8 |
| C | 0 | 207 | 70529 | 394.72 | 752 | 759 | 176.8 |
| D | 7 | 238 | 654299 | 3507.41 | 760 | 739 | 186.3 |
| D | 11 | 176 | 238763 | 1277.38 | 760 | 739 | 186.3 |
| D | 10 | 70 | 186109 | 994.81 | 760 | 739 | 186.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
