| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T04_9000002682_18054cztM0_level2.evt | modeM0/AS1A06_003T04_9000002682_18054cztM0_level2_quad_clean.evt |
| Size (bytes) | 598,550,400 | 110,560,320 |
| Size | 570.8 MB | 105.4 MB |
| Events in quadrant A | 3,869,585 | 718,004 |
| Events in quadrant B | 4,090,990 | 717,957 |
| Events in quadrant C | 4,418,357 | 684,183 |
| Events in quadrant D | 5,208,737 | 674,902 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16873 | 2 |
| B | 0 | 17378 | 2 |
| C | 0 | 18302 | 2 |
| D | 0 | 20875 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7959 | 95 | 1.193617% |
| B | 7960 | 132 | 1.658291% |
| C | 7960 | 300 | 3.768844% |
| D | 7960 | 284 | 3.567839% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8759 | 7962 | 12 | 12 | 0.14% | 0.15% |  |
| B | 8760 | 7963 | 9 | 9 | 0.10% | 0.11% |  |
| C | 8760 | 7963 | 125 | 125 | 1.43% | 1.57% |  |
| D | 8760 | 7963 | 180 | 180 | 2.05% | 2.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 142164 | 722.04 | 966 | 943 | 195.6 |
| A | 0 | 226 | 8316 | 37.7 | 966 | 943 | 195.6 |
| A | 3 | 137 | 7378 | 32.9 | 966 | 943 | 195.6 |
| B | 7 | 220 | 96148 | 515.98 | 962 | 935 | 184.5 |
| B | 3 | 64 | 78354 | 419.55 | 962 | 935 | 184.5 |
| B | 0 | 197 | 62862 | 335.6 | 962 | 935 | 184.5 |
| C | 9 | 160 | 346051 | 1591.12 | 922 | 929 | 216.9 |
| C | 9 | 176 | 271852 | 1249.04 | 922 | 929 | 216.9 |
| C | 14 | 238 | 142326 | 651.88 | 922 | 929 | 216.9 |
| D | 11 | 176 | 674846 | 2937.12 | 939 | 912 | 229.5 |
| D | 1 | 52 | 365629 | 1589.5 | 939 | 912 | 229.5 |
| D | 5 | 222 | 214077 | 929.01 | 939 | 912 | 229.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
