| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_019T01_9000002688_18105cztM0_level2.evt | modeM0/AS1A05_019T01_9000002688_18105cztM0_level2_quad_clean.evt |
| Size (bytes) | 686,508,480 | 77,912,640 |
| Size | 654.7 MB | 74.3 MB |
| Events in quadrant A | 3,358,194 | 549,810 |
| Events in quadrant B | 3,435,059 | 554,995 |
| Events in quadrant C | 3,284,731 | 519,606 |
| Events in quadrant D | 10,278,959 | 286,550 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14013 | 2 |
| B | 0 | 14157 | 3 |
| C | 0 | 13784 | 2 |
| D | 0 | 34744 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6408 | 94 | 1.466916% |
| B | 6407 | 107 | 1.670048% |
| C | 6407 | 113 | 1.763696% |
| D | 6407 | 3078 | 48.041205% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7578 | 6408 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7577 | 6407 | 6 | 6 | 0.08% | 0.09% |  |
| C | 7577 | 6407 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7577 | 6407 | 2718 | 2718 | 35.87% | 42.42% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 41998 | 238.39 | 862 | 847 | 172.6 |
| A | 0 | 226 | 7567 | 38.93 | 862 | 847 | 172.6 |
| A | 3 | 137 | 6130 | 30.6 | 862 | 847 | 172.6 |
| B | 0 | 189 | 37166 | 224.32 | 855 | 836 | 162.0 |
| B | 3 | 64 | 23080 | 137.35 | 855 | 836 | 162.0 |
| B | 12 | 111 | 18789 | 110.85 | 855 | 836 | 162.0 |
| C | 14 | 238 | 126205 | 670.48 | 805 | 812 | 187.0 |
| C | 3 | 233 | 8929 | 43.4 | 805 | 812 | 187.0 |
| C | 9 | 160 | 6316 | 29.43 | 805 | 812 | 187.0 |
| D | 7 | 238 | 7410797 | 49459.05 | 621 | 604 | 149.8 |
| D | 11 | 176 | 359809 | 2397.5 | 621 | 604 | 149.8 |
| D | 13 | 232 | 60555 | 400.14 | 621 | 604 | 149.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
