| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_019T01_9000002688_18116cztM0_level2.evt | modeM0/AS1A05_019T01_9000002688_18116cztM0_level2_quad_clean.evt |
| Size (bytes) | 514,192,320 | 82,339,200 |
| Size | 490.4 MB | 78.5 MB |
| Events in quadrant A | 3,581,742 | 504,884 |
| Events in quadrant B | 3,669,168 | 508,096 |
| Events in quadrant C | 3,568,072 | 485,878 |
| Events in quadrant D | 4,250,405 | 478,718 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15344 | 2 |
| B | 0 | 15505 | 2 |
| C | 0 | 15218 | 2 |
| D | 0 | 17653 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7410 | 46 | 0.620783% |
| B | 7410 | 65 | 0.877193% |
| C | 7411 | 70 | 0.944542% |
| D | 7411 | 99 | 1.335852% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9035 | 7412 | 8 | 8 | 0.09% | 0.11% |  |
| B | 9035 | 7412 | 13 | 13 | 0.14% | 0.18% |  |
| C | 9036 | 7413 | 3 | 3 | 0.03% | 0.04% |  |
| D | 9036 | 7413 | 69 | 69 | 0.76% | 0.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 107121 | 580.34 | 904 | 883 | 183.1 |
| A | 0 | 226 | 7806 | 37.82 | 904 | 883 | 183.1 |
| A | 3 | 137 | 6772 | 32.17 | 904 | 883 | 183.1 |
| B | 3 | 64 | 83186 | 469.15 | 903 | 880 | 175.4 |
| B | 12 | 111 | 20840 | 113.77 | 903 | 880 | 175.4 |
| B | 11 | 111 | 18558 | 100.77 | 903 | 880 | 175.4 |
| C | 14 | 238 | 132917 | 646.74 | 866 | 871 | 204.2 |
| C | 9 | 160 | 20398 | 95.64 | 866 | 871 | 204.2 |
| C | 0 | 207 | 17230 | 80.12 | 866 | 871 | 204.2 |
| D | 11 | 176 | 504300 | 2342.4 | 877 | 853 | 214.9 |
| D | 7 | 238 | 215223 | 997.4 | 877 | 853 | 214.9 |
| D | 1 | 52 | 138967 | 642.61 | 877 | 853 | 214.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
