| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_082T08_9000002698_18142cztM0_level2.evt | modeM0/AS1A05_082T08_9000002698_18142cztM0_level2_quad_clean.evt |
| Size (bytes) | 407,946,240 | 75,208,320 |
| Size | 389.0 MB | 71.7 MB |
| Events in quadrant A | 2,724,690 | 472,831 |
| Events in quadrant B | 2,799,170 | 481,912 |
| Events in quadrant C | 2,717,815 | 464,218 |
| Events in quadrant D | 3,721,040 | 455,497 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11955 | 1 |
| B | 0 | 12164 | 1 |
| C | 0 | 11890 | 1 |
| D | 0 | 14992 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5761 | 54 | 0.937337% |
| B | 5760 | 77 | 1.336806% |
| C | 5760 | 104 | 1.805556% |
| D | 5760 | 163 | 2.829861% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6091 | 5762 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6090 | 5761 | 4 | 4 | 0.07% | 0.07% |  |
| C | 6090 | 5761 | 0 | 0 | 0.00% | 0.00% |  |
| D | 6090 | 5761 | 86 | 86 | 1.41% | 1.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 46454 | 320.21 | 696 | 679 | 143.0 |
| A | 0 | 226 | 6149 | 38.26 | 696 | 679 | 143.0 |
| A | 3 | 137 | 5185 | 31.52 | 696 | 679 | 143.0 |
| B | 3 | 64 | 28015 | 200.63 | 696 | 677 | 136.3 |
| B | 12 | 111 | 16116 | 113.3 | 696 | 677 | 136.3 |
| B | 0 | 189 | 15326 | 107.51 | 696 | 677 | 136.3 |
| C | 14 | 238 | 101750 | 642.26 | 665 | 668 | 157.4 |
| C | 3 | 233 | 15428 | 93.78 | 665 | 668 | 157.4 |
| C | 0 | 207 | 5399 | 30.06 | 665 | 668 | 157.4 |
| D | 7 | 238 | 738334 | 4505.35 | 667 | 648 | 163.7 |
| D | 13 | 104 | 254275 | 1549.0 | 667 | 648 | 163.7 |
| D | 10 | 70 | 97892 | 593.91 | 667 | 648 | 163.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
