| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_194T05_9000002702_18156cztM0_level2.evt | modeM0/AS1A05_194T05_9000002702_18156cztM0_level2_quad_clean.evt |
| Size (bytes) | 661,875,840 | 93,934,080 |
| Size | 631.2 MB | 89.6 MB |
| Events in quadrant A | 4,309,200 | 572,844 |
| Events in quadrant B | 4,203,094 | 582,557 |
| Events in quadrant C | 5,412,654 | 553,171 |
| Events in quadrant D | 5,555,949 | 557,369 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18202 | 3 |
| B | 0 | 17845 | 2 |
| C | 0 | 21483 | 2 |
| D | 0 | 22295 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 172 | 0 |
| B | 0 | 172 | 0 |
| C | 0 | 172 | 0 |
| D | 0 | 172 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8321 | 153 | 1.838721% |
| B | 8322 | 177 | 2.126893% |
| C | 8322 | 541 | 6.500841% |
| D | 8322 | 258 | 3.100216% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8791 | 8323 | 38 | 38 | 0.43% | 0.46% |  |
| B | 8792 | 8324 | 6 | 6 | 0.07% | 0.07% |  |
| C | 8792 | 8324 | 197 | 197 | 2.24% | 2.37% |  |
| D | 8792 | 8324 | 108 | 108 | 1.23% | 1.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 269017 | 1260.63 | 1038 | 1015 | 212.6 |
| A | 4 | 2 | 48842 | 224.97 | 1038 | 1015 | 212.6 |
| A | 0 | 226 | 9158 | 38.3 | 1038 | 1015 | 212.6 |
| B | 0 | 197 | 38692 | 186.06 | 1038 | 1012 | 202.5 |
| B | 7 | 220 | 37799 | 181.65 | 1038 | 1012 | 202.5 |
| B | 12 | 111 | 23458 | 110.83 | 1038 | 1012 | 202.5 |
| C | 4 | 254 | 1377337 | 5984.03 | 982 | 985 | 230.0 |
| C | 14 | 238 | 151503 | 654.41 | 982 | 985 | 230.0 |
| C | 5 | 218 | 23568 | 98.18 | 982 | 985 | 230.0 |
| D | 7 | 238 | 1164919 | 4705.79 | 1006 | 974 | 247.3 |
| D | 12 | 233 | 119609 | 479.64 | 1006 | 974 | 247.3 |
| D | 13 | 187 | 109781 | 439.9 | 1006 | 974 | 247.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
