| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_019T01_9000002718_18249cztM0_level2.evt | modeM0/AS1A05_019T01_9000002718_18249cztM0_level2_quad_clean.evt |
| Size (bytes) | 455,316,480 | 69,713,280 |
| Size | 434.2 MB | 66.5 MB |
| Events in quadrant A | 3,187,291 | 422,562 |
| Events in quadrant B | 3,287,490 | 430,322 |
| Events in quadrant C | 3,202,907 | 404,676 |
| Events in quadrant D | 3,663,447 | 393,475 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13674 | 2 |
| B | 0 | 13928 | 2 |
| C | 0 | 13693 | 2 |
| D | 0 | 15207 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6594 | 45 | 0.682439% |
| B | 6594 | 55 | 0.834092% |
| C | 6594 | 55 | 0.834092% |
| D | 6594 | 127 | 1.925993% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7699 | 6595 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7699 | 6595 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7699 | 6595 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7699 | 6595 | 89 | 89 | 1.16% | 1.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 30011 | 176.76 | 818 | 802 | 165.3 |
| A | 11 | 29 | 9206 | 50.86 | 818 | 802 | 165.3 |
| A | 0 | 226 | 7124 | 38.26 | 818 | 802 | 165.3 |
| B | 7 | 220 | 66603 | 416.96 | 820 | 799 | 157.8 |
| B | 12 | 111 | 18410 | 111.59 | 820 | 799 | 157.8 |
| B | 11 | 111 | 15711 | 94.49 | 820 | 799 | 157.8 |
| C | 14 | 238 | 123182 | 663.99 | 786 | 792 | 184.3 |
| C | 0 | 207 | 10061 | 50.29 | 786 | 792 | 184.3 |
| C | 3 | 233 | 7354 | 35.6 | 786 | 792 | 184.3 |
| D | 1 | 52 | 486791 | 2538.03 | 789 | 766 | 191.5 |
| D | 7 | 238 | 66811 | 344.89 | 789 | 766 | 191.5 |
| D | 13 | 168 | 65595 | 338.54 | 789 | 766 | 191.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
