| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_006T01_9000002720_18271cztM0_level2.evt | modeM0/AS1A06_006T01_9000002720_18271cztM0_level2_quad_clean.evt |
| Size (bytes) | 646,920,000 | 107,726,400 |
| Size | 617.0 MB | 102.7 MB |
| Events in quadrant A | 3,752,038 | 705,638 |
| Events in quadrant B | 3,898,255 | 702,588 |
| Events in quadrant C | 3,755,427 | 681,702 |
| Events in quadrant D | 7,667,202 | 638,912 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16112 | 1 |
| B | 0 | 16435 | 1 |
| C | 0 | 16131 | 1 |
| D | 0 | 28342 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7672 | 110 | 1.433785% |
| B | 7672 | 152 | 1.981230% |
| C | 7672 | 154 | 2.007299% |
| D | 7672 | 671 | 8.746090% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7822 | 7674 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7822 | 7674 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7822 | 7674 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7822 | 7674 | 412 | 412 | 5.27% | 5.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 40241 | 200.19 | 965 | 944 | 196.3 |
| A | 0 | 226 | 8636 | 39.18 | 965 | 944 | 196.3 |
| A | 3 | 137 | 7164 | 31.69 | 965 | 944 | 196.3 |
| B | 7 | 220 | 36244 | 189.54 | 958 | 932 | 186.3 |
| B | 4 | 216 | 26539 | 137.45 | 958 | 932 | 186.3 |
| B | 0 | 190 | 25004 | 129.21 | 958 | 932 | 186.3 |
| C | 14 | 238 | 140009 | 643.26 | 915 | 922 | 216.2 |
| C | 3 | 233 | 30701 | 137.72 | 915 | 922 | 216.2 |
| C | 0 | 207 | 19237 | 84.7 | 915 | 922 | 216.2 |
| D | 7 | 238 | 2079170 | 9206.06 | 913 | 885 | 225.8 |
| D | 13 | 168 | 959837 | 4247.82 | 913 | 885 | 225.8 |
| D | 1 | 52 | 845775 | 3742.56 | 913 | 885 | 225.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
