| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_006T01_9000002720_18293cztM0_level2.evt | modeM0/AS1A06_006T01_9000002720_18293cztM0_level2_quad_clean.evt |
| Size (bytes) | 569,142,720 | 73,226,880 |
| Size | 542.8 MB | 69.8 MB |
| Events in quadrant A | 3,336,064 | 455,587 |
| Events in quadrant B | 3,339,496 | 461,764 |
| Events in quadrant C | 3,240,524 | 448,306 |
| Events in quadrant D | 6,876,062 | 393,824 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13997 | 2 |
| B | 0 | 13907 | 2 |
| C | 0 | 13612 | 2 |
| D | 0 | 24914 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6555 | 42 | 0.640732% |
| B | 6555 | 43 | 0.655988% |
| C | 6555 | 63 | 0.961098% |
| D | 6555 | 803 | 12.250191% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7735 | 6556 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7735 | 6556 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7735 | 6556 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7735 | 6556 | 741 | 741 | 9.58% | 11.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 103522 | 623.61 | 823 | 807 | 164.7 |
| A | 9 | 143 | 60956 | 365.18 | 823 | 807 | 164.7 |
| A | 12 | 194 | 7296 | 39.4 | 823 | 807 | 164.7 |
| B | 7 | 220 | 37200 | 232.26 | 830 | 812 | 156.7 |
| B | 0 | 189 | 21292 | 130.72 | 830 | 812 | 156.7 |
| B | 12 | 111 | 17713 | 107.88 | 830 | 812 | 156.7 |
| C | 14 | 238 | 124789 | 672.98 | 794 | 803 | 184.2 |
| C | 0 | 207 | 15993 | 82.45 | 794 | 803 | 184.2 |
| C | 13 | 61 | 5684 | 26.49 | 794 | 803 | 184.2 |
| D | 7 | 238 | 3366585 | 17982.93 | 770 | 747 | 187.2 |
| D | 1 | 52 | 335363 | 1787.78 | 770 | 747 | 187.2 |
| D | 13 | 168 | 128332 | 681.66 | 770 | 747 | 187.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
