| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_006T01_9000002720_18315cztM0_level2.evt | modeM0/AS1A06_006T01_9000002720_18315cztM0_level2_quad_clean.evt |
| Size (bytes) | 536,895,360 | 98,663,040 |
| Size | 512.0 MB | 94.1 MB |
| Events in quadrant A | 3,431,736 | 634,482 |
| Events in quadrant B | 3,905,143 | 629,365 |
| Events in quadrant C | 3,443,479 | 622,350 |
| Events in quadrant D | 4,986,592 | 595,787 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14950 | 2 |
| B | 0 | 16162 | 1 |
| C | 0 | 14958 | 1 |
| D | 0 | 19470 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7270 | 58 | 0.797799% |
| B | 7270 | 109 | 1.499312% |
| C | 7270 | 91 | 1.251719% |
| D | 7270 | 227 | 3.122421% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7565 | 7271 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7565 | 7271 | 20 | 20 | 0.26% | 0.28% |  |
| C | 7565 | 7271 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7565 | 7271 | 234 | 234 | 3.09% | 3.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 9681 | 48.54 | 890 | 869 | 181.5 |
| A | 0 | 226 | 7917 | 38.82 | 890 | 869 | 181.5 |
| A | 12 | 194 | 6730 | 32.28 | 890 | 869 | 181.5 |
| B | 7 | 220 | 226573 | 1327.44 | 883 | 863 | 170.0 |
| B | 4 | 216 | 38636 | 222.15 | 883 | 863 | 170.0 |
| B | 10 | 247 | 37480 | 215.35 | 883 | 863 | 170.0 |
| C | 14 | 238 | 129617 | 639.54 | 848 | 853 | 201.3 |
| C | 13 | 61 | 5928 | 25.21 | 848 | 853 | 201.3 |
| C | 0 | 207 | 4574 | 18.48 | 848 | 853 | 201.3 |
| D | 7 | 238 | 749301 | 3552.58 | 858 | 833 | 210.7 |
| D | 13 | 168 | 575991 | 2729.97 | 858 | 833 | 210.7 |
| D | 14 | 34 | 124340 | 586.22 | 858 | 833 | 210.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
