| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_006T01_9000002720_18339cztM0_level2.evt | modeM0/AS1A06_006T01_9000002720_18339cztM0_level2_quad_clean.evt |
| Size (bytes) | 456,048,000 | 62,686,080 |
| Size | 434.9 MB | 59.8 MB |
| Events in quadrant A | 3,108,758 | 374,696 |
| Events in quadrant B | 3,324,898 | 380,130 |
| Events in quadrant C | 3,197,860 | 370,755 |
| Events in quadrant D | 3,779,699 | 360,264 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12524 | 1 |
| B | 0 | 13256 | 1 |
| C | 0 | 12822 | 1 |
| D | 0 | 15300 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5896 | 53 | 0.898915% |
| B | 5896 | 85 | 1.441655% |
| C | 5896 | 121 | 2.052239% |
| D | 5896 | 68 | 1.153324% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7226 | 5897 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7226 | 5897 | 15 | 15 | 0.21% | 0.25% |  |
| C | 7226 | 5897 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7226 | 5897 | 5 | 5 | 0.07% | 0.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 34047 | 209.07 | 799 | 784 | 159.1 |
| A | 0 | 226 | 7164 | 40.1 | 799 | 784 | 159.1 |
| A | 12 | 194 | 5725 | 31.06 | 799 | 784 | 159.1 |
| B | 7 | 220 | 115733 | 770.54 | 801 | 784 | 149.2 |
| B | 4 | 171 | 32869 | 215.07 | 801 | 784 | 149.2 |
| B | 12 | 111 | 16311 | 104.08 | 801 | 784 | 149.2 |
| C | 14 | 238 | 122502 | 684.56 | 773 | 782 | 177.8 |
| C | 3 | 233 | 49491 | 273.94 | 773 | 782 | 177.8 |
| C | 0 | 207 | 11077 | 57.9 | 773 | 782 | 177.8 |
| D | 1 | 52 | 651012 | 3425.85 | 782 | 760 | 189.8 |
| D | 14 | 34 | 90651 | 473.59 | 782 | 760 | 189.8 |
| D | 11 | 176 | 27674 | 141.79 | 782 | 760 | 189.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
