| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_006T01_9000002720_18352cztM0_level2.evt | modeM0/AS1A06_006T01_9000002720_18352cztM0_level2_quad_clean.evt |
| Size (bytes) | 461,684,160 | 70,738,560 |
| Size | 440.3 MB | 67.5 MB |
| Events in quadrant A | 3,177,744 | 430,782 |
| Events in quadrant B | 3,421,653 | 438,718 |
| Events in quadrant C | 3,450,714 | 420,799 |
| Events in quadrant D | 3,502,747 | 410,479 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13130 | 1 |
| B | 0 | 13912 | 1 |
| C | 0 | 13956 | 1 |
| D | 0 | 14331 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6321 | 20 | 0.316406% |
| B | 6321 | 48 | 0.759374% |
| C | 6322 | 120 | 1.898134% |
| D | 6322 | 55 | 0.869978% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7591 | 6322 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7591 | 6322 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7592 | 6323 | 32 | 32 | 0.42% | 0.51% |  |
| D | 7592 | 6323 | 16 | 16 | 0.21% | 0.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 18111 | 104.74 | 819 | 803 | 165.2 |
| A | 4 | 2 | 12009 | 67.82 | 819 | 803 | 165.2 |
| A | 0 | 226 | 7217 | 38.82 | 819 | 803 | 165.2 |
| B | 7 | 220 | 88466 | 562.77 | 829 | 810 | 155.8 |
| B | 4 | 48 | 41540 | 261.49 | 829 | 810 | 155.8 |
| B | 0 | 189 | 26049 | 162.04 | 829 | 810 | 155.8 |
| C | 4 | 254 | 143562 | 789.62 | 788 | 796 | 180.8 |
| C | 14 | 238 | 123700 | 679.77 | 788 | 796 | 180.8 |
| C | 0 | 207 | 101200 | 555.32 | 788 | 796 | 180.8 |
| D | 1 | 52 | 361429 | 1863.59 | 795 | 775 | 193.5 |
| D | 13 | 104 | 37761 | 191.12 | 795 | 775 | 193.5 |
| D | 2 | 234 | 29527 | 148.57 | 795 | 775 | 193.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
