| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_094T01_9000002726_18395cztM0_level2.evt | modeM0/AS1A05_094T01_9000002726_18395cztM0_level2_quad_clean.evt |
| Size (bytes) | 450,918,720 | 95,719,680 |
| Size | 430.0 MB | 91.3 MB |
| Events in quadrant A | 3,128,421 | 631,753 |
| Events in quadrant B | 3,125,341 | 648,597 |
| Events in quadrant C | 3,496,318 | 598,481 |
| Events in quadrant D | 3,479,208 | 581,655 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13304 | 2 |
| B | 0 | 13351 | 2 |
| C | 0 | 14461 | 2 |
| D | 0 | 14646 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6287 | 13 | 0.206776% |
| B | 6287 | 16 | 0.254493% |
| C | 6287 | 223 | 3.547002% |
| D | 6287 | 113 | 1.797360% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7552 | 6288 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7552 | 6288 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7552 | 6288 | 125 | 125 | 1.66% | 1.99% |  |
| D | 7552 | 6288 | 87 | 87 | 1.15% | 1.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 210 | 41951 | 263.19 | 782 | 769 | 156.5 |
| A | 15 | 174 | 33068 | 206.42 | 782 | 769 | 156.5 |
| A | 8 | 34 | 26602 | 165.1 | 782 | 769 | 156.5 |
| B | 3 | 64 | 19677 | 128.63 | 788 | 768 | 147.0 |
| B | 12 | 111 | 16623 | 107.86 | 788 | 768 | 147.0 |
| B | 11 | 111 | 14294 | 92.01 | 788 | 768 | 147.0 |
| C | 5 | 112 | 442794 | 2529.12 | 753 | 762 | 174.8 |
| C | 14 | 238 | 117179 | 666.09 | 753 | 762 | 174.8 |
| C | 13 | 61 | 5299 | 25.96 | 753 | 762 | 174.8 |
| D | 1 | 52 | 490784 | 2702.13 | 755 | 735 | 181.4 |
| D | 12 | 110 | 40468 | 219.09 | 755 | 735 | 181.4 |
| D | 13 | 104 | 37482 | 202.62 | 755 | 735 | 181.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
