| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_094T01_9000002726_18396cztM0_level2.evt | modeM0/AS1A05_094T01_9000002726_18396cztM0_level2_quad_clean.evt |
| Size (bytes) | 434,736,000 | 95,659,200 |
| Size | 414.6 MB | 91.2 MB |
| Events in quadrant A | 3,114,312 | 627,939 |
| Events in quadrant B | 3,321,884 | 648,642 |
| Events in quadrant C | 3,068,016 | 610,375 |
| Events in quadrant D | 3,245,180 | 582,030 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13150 | 2 |
| B | 0 | 13605 | 3 |
| C | 0 | 12939 | 2 |
| D | 0 | 13742 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6133 | 29 | 0.472852% |
| B | 6132 | 39 | 0.636008% |
| C | 6132 | 42 | 0.684932% |
| D | 6132 | 54 | 0.880626% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7453 | 6134 | 6 | 6 | 0.08% | 0.10% |  |
| B | 7452 | 6133 | 16 | 16 | 0.21% | 0.26% |  |
| C | 7452 | 6133 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7452 | 6133 | 42 | 42 | 0.56% | 0.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 68798 | 437.1 | 777 | 763 | 155.7 |
| A | 15 | 174 | 28898 | 180.76 | 777 | 763 | 155.7 |
| A | 13 | 210 | 20333 | 125.73 | 777 | 763 | 155.7 |
| B | 3 | 64 | 192861 | 1336.86 | 786 | 768 | 143.7 |
| B | 10 | 245 | 19596 | 131.03 | 786 | 768 | 143.7 |
| B | 12 | 111 | 16559 | 109.9 | 786 | 768 | 143.7 |
| C | 14 | 238 | 118997 | 673.73 | 755 | 761 | 175.5 |
| C | 13 | 61 | 5300 | 25.86 | 755 | 761 | 175.5 |
| C | 5 | 252 | 4202 | 19.61 | 755 | 761 | 175.5 |
| D | 1 | 52 | 169592 | 935.51 | 748 | 726 | 180.5 |
| D | 2 | 152 | 95207 | 523.42 | 748 | 726 | 180.5 |
| D | 12 | 110 | 59152 | 323.68 | 748 | 726 | 180.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
