| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_094T01_9000002726_18402cztM0_level2.evt | modeM0/AS1A05_094T01_9000002726_18402cztM0_level2_quad_clean.evt |
| Size (bytes) | 529,297,920 | 87,451,200 |
| Size | 504.8 MB | 83.4 MB |
| Events in quadrant A | 3,800,456 | 535,534 |
| Events in quadrant B | 3,891,615 | 542,530 |
| Events in quadrant C | 3,842,157 | 513,884 |
| Events in quadrant D | 3,953,788 | 502,188 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16643 | 2 |
| B | 0 | 16763 | 2 |
| C | 0 | 16602 | 2 |
| D | 0 | 17099 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7973 | 381 | 4.778628% |
| B | 7974 | 421 | 5.279659% |
| C | 7974 | 402 | 5.041384% |
| D | 7974 | 351 | 4.401806% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8363 | 7975 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8364 | 7976 | 12 | 12 | 0.14% | 0.15% |  |
| C | 8364 | 7976 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8364 | 7976 | 12 | 12 | 0.14% | 0.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 42895 | 211.8 | 973 | 949 | 198.0 |
| A | 0 | 226 | 8504 | 38.15 | 973 | 949 | 198.0 |
| A | 15 | 174 | 7916 | 35.18 | 973 | 949 | 198.0 |
| B | 7 | 220 | 55052 | 287.44 | 973 | 945 | 188.2 |
| B | 0 | 189 | 25687 | 131.44 | 973 | 945 | 188.2 |
| B | 12 | 111 | 22905 | 116.66 | 973 | 945 | 188.2 |
| C | 14 | 238 | 142185 | 644.41 | 933 | 938 | 219.2 |
| C | 3 | 233 | 44649 | 199.42 | 933 | 938 | 219.2 |
| C | 8 | 128 | 9159 | 37.51 | 933 | 938 | 219.2 |
| D | 1 | 52 | 175619 | 755.93 | 944 | 913 | 231.1 |
| D | 7 | 238 | 78761 | 336.84 | 944 | 913 | 231.1 |
| D | 8 | 195 | 36733 | 154.99 | 944 | 913 | 231.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
