| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_075T09_9000002740_18487cztM0_level2.evt | modeM0/AS1A05_075T09_9000002740_18487cztM0_level2_quad_clean.evt |
| Size (bytes) | 702,947,520 | 93,087,360 |
| Size | 670.4 MB | 88.8 MB |
| Events in quadrant A | 9,027,997 | 495,270 |
| Events in quadrant B | 3,580,872 | 628,566 |
| Events in quadrant C | 4,451,117 | 608,072 |
| Events in quadrant D | 3,747,523 | 591,221 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31698 | 1 |
| B | 0 | 15243 | 1 |
| C | 0 | 18071 | 1 |
| D | 0 | 16211 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7107 | 2304 | 32.418742% |
| B | 7108 | 135 | 1.899268% |
| C | 7108 | 164 | 2.307259% |
| D | 7108 | 169 | 2.377603% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7557 | 7107 | 1885 | 1885 | 24.94% | 26.52% |  |
| B | 7558 | 7108 | 18 | 18 | 0.24% | 0.25% |  |
| C | 7558 | 7108 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7558 | 7109 | 89 | 89 | 1.18% | 1.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 6012092 | 39716.94 | 740 | 724 | 151.4 |
| A | 15 | 174 | 125914 | 827.13 | 740 | 724 | 151.4 |
| A | 4 | 2 | 36348 | 235.37 | 740 | 724 | 151.4 |
| B | 10 | 245 | 163591 | 974.16 | 860 | 838 | 167.1 |
| B | 7 | 220 | 25816 | 149.51 | 860 | 838 | 167.1 |
| B | 12 | 111 | 20201 | 115.9 | 860 | 838 | 167.1 |
| C | 3 | 233 | 1102239 | 5644.82 | 824 | 830 | 195.1 |
| C | 14 | 238 | 126787 | 645.54 | 824 | 830 | 195.1 |
| C | 13 | 61 | 5772 | 25.33 | 824 | 830 | 195.1 |
| D | 7 | 238 | 557098 | 2738.6 | 831 | 806 | 203.1 |
| D | 2 | 234 | 32683 | 156.93 | 831 | 806 | 203.1 |
| D | 7 | 38 | 16457 | 77.05 | 831 | 806 | 203.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
