| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_083T01_9000002742_18495cztM0_level2.evt | modeM0/AS1T03_083T01_9000002742_18495cztM0_level2_quad_clean.evt |
| Size (bytes) | 438,488,640 | 119,260,800 |
| Size | 418.2 MB | 113.7 MB |
| Events in quadrant A | 3,471,104 | 812,827 |
| Events in quadrant B | 3,165,391 | 824,938 |
| Events in quadrant C | 3,023,476 | 779,774 |
| Events in quadrant D | 3,195,853 | 759,575 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14374 | 1 |
| B | 0 | 13472 | 1 |
| C | 0 | 13040 | 1 |
| D | 0 | 13706 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6236 | 120 | 1.924310% |
| B | 6237 | 58 | 0.929934% |
| C | 6237 | 79 | 1.266635% |
| D | 6237 | 69 | 1.106301% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7351 | 6236 | 33 | 33 | 0.45% | 0.53% |  |
| B | 7352 | 6237 | 7 | 7 | 0.10% | 0.11% |  |
| C | 7352 | 6237 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7352 | 6237 | 33 | 33 | 0.45% | 0.53% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 453777 | 2902.14 | 779 | 765 | 156.1 |
| A | 15 | 192 | 12746 | 76.75 | 779 | 765 | 156.1 |
| A | 13 | 254 | 8143 | 47.27 | 779 | 765 | 156.1 |
| B | 10 | 245 | 29354 | 192.71 | 778 | 761 | 148.4 |
| B | 0 | 245 | 24405 | 159.36 | 778 | 761 | 148.4 |
| B | 7 | 220 | 23300 | 151.91 | 778 | 761 | 148.4 |
| C | 14 | 238 | 117285 | 679.6 | 738 | 744 | 171.5 |
| C | 3 | 233 | 22543 | 127.12 | 738 | 744 | 171.5 |
| C | 13 | 61 | 5312 | 26.64 | 738 | 744 | 171.5 |
| D | 7 | 238 | 211292 | 1172.9 | 745 | 724 | 179.5 |
| D | 12 | 110 | 67127 | 369.87 | 745 | 724 | 179.5 |
| D | 1 | 52 | 52468 | 288.22 | 745 | 724 | 179.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
