| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_187T03_9000002748_18518cztM0_level2.evt | modeM0/AS1A05_187T03_9000002748_18518cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,041,010,560 | 84,528,000 |
| Size | 992.8 MB | 80.6 MB |
| Events in quadrant A | 6,460,496 | 533,472 |
| Events in quadrant B | 4,406,348 | 563,227 |
| Events in quadrant C | 4,451,418 | 541,376 |
| Events in quadrant D | 15,646,853 | 341,023 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24767 | 2 |
| B | 0 | 18484 | 2 |
| C | 0 | 18495 | 2 |
| D | 0 | 52040 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 172 | 0 |
| B | 0 | 172 | 0 |
| C | 0 | 172 | 0 |
| D | 0 | 172 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8326 | 879 | 10.557290% |
| B | 8326 | 380 | 4.564016% |
| C | 8327 | 271 | 3.254473% |
| D | 8327 | 4752 | 57.067371% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8656 | 8326 | 504 | 504 | 5.82% | 6.05% |  |
| B | 8656 | 8326 | 37 | 37 | 0.43% | 0.44% |  |
| C | 8657 | 8327 | 3 | 3 | 0.03% | 0.04% |  |
| D | 8657 | 8328 | 4597 | 4597 | 53.10% | 55.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 2531724 | 12205.23 | 1010 | 986 | 207.3 |
| A | 15 | 192 | 14255 | 63.99 | 1010 | 986 | 207.3 |
| A | 14 | 111 | 14250 | 63.97 | 1010 | 986 | 207.3 |
| B | 3 | 64 | 113603 | 548.28 | 1039 | 1010 | 205.4 |
| B | 7 | 220 | 94316 | 454.36 | 1039 | 1010 | 205.4 |
| B | 0 | 228 | 34620 | 163.67 | 1039 | 1010 | 205.4 |
| C | 3 | 233 | 374474 | 1568.98 | 996 | 1002 | 238.0 |
| C | 14 | 238 | 151883 | 633.86 | 996 | 1002 | 238.0 |
| C | 9 | 54 | 23042 | 92.59 | 996 | 1002 | 238.0 |
| D | 13 | 168 | 8974159 | 52509.66 | 685 | 663 | 170.9 |
| D | 1 | 52 | 2971956 | 17386.93 | 685 | 663 | 170.9 |
| D | 7 | 238 | 1006444 | 5885.46 | 685 | 663 | 170.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
