| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_187T03_9000002748_18530cztM0_level2.evt | modeM0/AS1A05_187T03_9000002748_18530cztM0_level2_quad_clean.evt |
| Size (bytes) | 535,942,080 | 90,331,200 |
| Size | 511.1 MB | 86.1 MB |
| Events in quadrant A | 3,376,742 | 578,521 |
| Events in quadrant B | 3,569,555 | 584,017 |
| Events in quadrant C | 4,066,305 | 556,526 |
| Events in quadrant D | 4,750,942 | 536,065 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14594 | 2 |
| B | 0 | 15046 | 2 |
| C | 0 | 16610 | 2 |
| D | 0 | 18843 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6894 | 34 | 0.493182% |
| B | 6894 | 81 | 1.174935% |
| C | 6894 | 145 | 2.103278% |
| D | 6894 | 175 | 2.538439% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7674 | 6895 | 10 | 10 | 0.13% | 0.15% |  |
| B | 7674 | 6895 | 54 | 54 | 0.70% | 0.78% |  |
| C | 7674 | 6895 | 38 | 38 | 0.50% | 0.55% |  |
| D | 7674 | 6895 | 148 | 148 | 1.93% | 2.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 135809 | 797.05 | 830 | 813 | 169.4 |
| A | 9 | 143 | 19325 | 109.3 | 830 | 813 | 169.4 |
| A | 13 | 254 | 9960 | 54.01 | 830 | 813 | 169.4 |
| B | 7 | 220 | 149236 | 930.51 | 828 | 805 | 159.5 |
| B | 15 | 222 | 71148 | 440.98 | 828 | 805 | 159.5 |
| B | 0 | 183 | 39154 | 240.41 | 828 | 805 | 159.5 |
| C | 9 | 54 | 646438 | 3451.18 | 796 | 801 | 187.1 |
| C | 14 | 238 | 124706 | 662.32 | 796 | 801 | 187.1 |
| C | 3 | 233 | 123147 | 653.99 | 796 | 801 | 187.1 |
| D | 13 | 168 | 1112112 | 5713.3 | 797 | 776 | 194.5 |
| D | 7 | 238 | 358144 | 1837.2 | 797 | 776 | 194.5 |
| D | 1 | 52 | 121856 | 622.46 | 797 | 776 | 194.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
