| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_104T03_9000002770_18605cztM0_level2.evt | modeM0/AS1A05_104T03_9000002770_18605cztM0_level2_quad_clean.evt |
| Size (bytes) | 620,910,720 | 120,879,360 |
| Size | 592.1 MB | 115.3 MB |
| Events in quadrant A | 3,982,065 | 778,182 |
| Events in quadrant B | 4,119,443 | 797,550 |
| Events in quadrant C | 4,343,486 | 771,325 |
| Events in quadrant D | 5,791,070 | 731,567 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17566 | 2 |
| B | 0 | 17800 | 2 |
| C | 0 | 18301 | 2 |
| D | 0 | 23151 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 170 | 0 |
| B | 0 | 170 | 0 |
| C | 0 | 170 | 0 |
| D | 0 | 170 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8373 | 208 | 2.484175% |
| B | 8373 | 266 | 3.176878% |
| C | 8373 | 330 | 3.941240% |
| D | 8374 | 562 | 6.711249% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8643 | 8375 | 1 | 1 | 0.01% | 0.01% |  |
| B | 8643 | 8375 | 0 | 0 | 0.00% | 0.00% |  |
| C | 8643 | 8375 | 54 | 54 | 0.62% | 0.64% |  |
| D | 8644 | 8376 | 370 | 370 | 4.28% | 4.42% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12597 | 55.05 | 1030 | 1006 | 210.6 |
| A | 0 | 226 | 8997 | 37.95 | 1030 | 1006 | 210.6 |
| A | 3 | 137 | 8543 | 35.79 | 1030 | 1006 | 210.6 |
| B | 0 | 229 | 37956 | 184.66 | 1031 | 1001 | 200.1 |
| B | 12 | 111 | 25075 | 120.29 | 1031 | 1001 | 200.1 |
| B | 11 | 111 | 21898 | 104.42 | 1031 | 1001 | 200.1 |
| C | 3 | 233 | 235169 | 992.84 | 993 | 1000 | 235.9 |
| C | 14 | 238 | 152296 | 641.47 | 993 | 1000 | 235.9 |
| C | 9 | 54 | 65353 | 272.85 | 993 | 1000 | 235.9 |
| D | 1 | 52 | 1435142 | 5917.76 | 983 | 954 | 242.4 |
| D | 7 | 238 | 468285 | 1928.31 | 983 | 954 | 242.4 |
| D | 7 | 96 | 129823 | 531.74 | 983 | 954 | 242.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
