| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C04_001T01_9000002784_18631cztM0_level2.evt | modeM0/AS1C04_001T01_9000002784_18631cztM0_level2_quad_clean.evt |
| Size (bytes) | 466,246,080 | 124,441,920 |
| Size | 444.6 MB | 118.7 MB |
| Events in quadrant A | 3,303,327 | 821,540 |
| Events in quadrant B | 3,290,160 | 845,415 |
| Events in quadrant C | 3,483,216 | 830,800 |
| Events in quadrant D | 3,588,311 | 804,260 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14400 | 2 |
| B | 0 | 14103 | 2 |
| C | 0 | 14762 | 2 |
| D | 0 | 15381 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6701 | 46 | 0.686465% |
| B | 6701 | 35 | 0.522310% |
| C | 6701 | 133 | 1.984778% |
| D | 6701 | 112 | 1.671392% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7651 | 6702 | 29 | 29 | 0.38% | 0.43% |  |
| B | 7651 | 6702 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7651 | 6702 | 19 | 19 | 0.25% | 0.28% |  |
| D | 7651 | 6702 | 65 | 65 | 0.85% | 0.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 168350 | 1037.05 | 801 | 785 | 161.6 |
| A | 9 | 143 | 42683 | 259.3 | 801 | 785 | 161.6 |
| A | 13 | 254 | 10403 | 59.53 | 801 | 785 | 161.6 |
| B | 0 | 189 | 29242 | 188.54 | 808 | 788 | 150.9 |
| B | 0 | 197 | 26260 | 168.78 | 808 | 788 | 150.9 |
| B | 0 | 229 | 18839 | 119.61 | 808 | 788 | 150.9 |
| C | 3 | 233 | 157288 | 861.67 | 790 | 795 | 181.6 |
| C | 14 | 238 | 122959 | 672.65 | 790 | 795 | 181.6 |
| C | 9 | 54 | 77934 | 424.74 | 790 | 795 | 181.6 |
| D | 1 | 52 | 299056 | 1574.74 | 791 | 769 | 189.4 |
| D | 14 | 34 | 141153 | 741.13 | 791 | 769 | 189.4 |
| D | 7 | 238 | 80386 | 420.32 | 791 | 769 | 189.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
