| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C04_001T01_9000002784_18632cztM0_level2.evt | modeM0/AS1C04_001T01_9000002784_18632cztM0_level2_quad_clean.evt |
| Size (bytes) | 501,480,000 | 126,334,080 |
| Size | 478.2 MB | 120.5 MB |
| Events in quadrant A | 3,299,324 | 833,710 |
| Events in quadrant B | 3,528,513 | 850,592 |
| Events in quadrant C | 3,456,894 | 837,314 |
| Events in quadrant D | 4,417,432 | 807,282 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14799 | 3 |
| B | 0 | 15307 | 2 |
| C | 0 | 15013 | 2 |
| D | 0 | 18039 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7154 | 31 | 0.433324% |
| B | 7154 | 73 | 1.020408% |
| C | 7154 | 121 | 1.691361% |
| D | 7154 | 141 | 1.970925% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7664 | 7155 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7664 | 7155 | 6 | 6 | 0.08% | 0.08% |  |
| C | 7664 | 7155 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7664 | 7155 | 107 | 107 | 1.40% | 1.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 38362 | 218.46 | 845 | 826 | 171.8 |
| A | 13 | 254 | 11408 | 61.59 | 845 | 826 | 171.8 |
| A | 0 | 226 | 7232 | 37.28 | 845 | 826 | 171.8 |
| B | 7 | 220 | 47683 | 290.71 | 852 | 830 | 161.2 |
| B | 0 | 230 | 31778 | 192.02 | 852 | 830 | 161.2 |
| B | 6 | 36 | 25979 | 156.04 | 852 | 830 | 161.2 |
| C | 14 | 238 | 128100 | 661.08 | 830 | 835 | 192.5 |
| C | 9 | 54 | 76258 | 391.79 | 830 | 835 | 192.5 |
| C | 3 | 233 | 11767 | 56.79 | 830 | 835 | 192.5 |
| D | 1 | 52 | 612452 | 3066.98 | 829 | 804 | 199.4 |
| D | 7 | 238 | 293736 | 1468.85 | 829 | 804 | 199.4 |
| D | 14 | 34 | 270588 | 1352.77 | 829 | 804 | 199.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
