| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C04_001T01_9000002784_18636cztM0_level2.evt | modeM0/AS1C04_001T01_9000002784_18636cztM0_level2_quad_clean.evt |
| Size (bytes) | 625,032,000 | 135,282,240 |
| Size | 596.1 MB | 129.0 MB |
| Events in quadrant A | 3,877,699 | 883,426 |
| Events in quadrant B | 5,412,253 | 870,573 |
| Events in quadrant C | 3,870,396 | 896,974 |
| Events in quadrant D | 5,191,146 | 854,607 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 174 | 0 |
| B | 0 | 174 | 0 |
| C | 0 | 174 | 0 |
| D | 0 | 174 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17536 | 1 |
| B | 0 | 22110 | 1 |
| C | 0 | 17431 | 1 |
| D | 0 | 21453 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8511 | 72 | 0.845964% |
| B | 8512 | 568 | 6.672932% |
| C | 8512 | 82 | 0.963346% |
| D | 8512 | 305 | 3.583177% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8951 | 8511 | 16 | 16 | 0.18% | 0.19% |  |
| B | 8952 | 8513 | 405 | 405 | 4.52% | 4.76% |  |
| C | 8952 | 8513 | 8 | 8 | 0.09% | 0.09% |  |
| D | 8952 | 8513 | 235 | 235 | 2.63% | 2.76% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 83038 | 418.25 | 968 | 947 | 196.3 |
| A | 4 | 2 | 35863 | 177.9 | 968 | 947 | 196.3 |
| A | 13 | 254 | 13215 | 62.51 | 968 | 947 | 196.3 |
| B | 10 | 245 | 1590009 | 8973.01 | 935 | 910 | 177.1 |
| B | 7 | 220 | 46284 | 256.21 | 935 | 910 | 177.1 |
| B | 0 | 230 | 42432 | 234.46 | 935 | 910 | 177.1 |
| C | 14 | 238 | 144946 | 665.12 | 936 | 944 | 216.5 |
| C | 9 | 54 | 58434 | 265.54 | 936 | 944 | 216.5 |
| C | 3 | 233 | 18032 | 78.93 | 936 | 944 | 216.5 |
| D | 1 | 52 | 1435948 | 6417.83 | 929 | 904 | 223.6 |
| D | 7 | 238 | 125318 | 556.41 | 929 | 904 | 223.6 |
| D | 14 | 34 | 44464 | 194.81 | 929 | 904 | 223.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
