| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_072T04_9000002794_18687cztM0_level2.evt | modeM0/AS1A05_072T04_9000002794_18687cztM0_level2_quad_clean.evt |
| Size (bytes) | 491,823,360 | 71,424,000 |
| Size | 469.0 MB | 68.1 MB |
| Events in quadrant A | 3,398,779 | 433,423 |
| Events in quadrant B | 3,734,965 | 438,888 |
| Events in quadrant C | 3,696,838 | 427,296 |
| Events in quadrant D | 3,637,374 | 424,014 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14108 | 3 |
| B | 0 | 15123 | 2 |
| C | 0 | 15109 | 2 |
| D | 0 | 14869 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6289 | 113 | 1.796788% |
| B | 6289 | 205 | 3.259660% |
| C | 6289 | 194 | 3.084751% |
| D | 6289 | 172 | 2.734934% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7604 | 6290 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7604 | 6290 | 59 | 59 | 0.78% | 0.94% |  |
| C | 7604 | 6290 | 20 | 20 | 0.26% | 0.32% |  |
| D | 7604 | 6290 | 62 | 62 | 0.82% | 0.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 12368 | 66.1 | 876 | 861 | 174.1 |
| A | 13 | 254 | 10620 | 56.06 | 876 | 861 | 174.1 |
| A | 11 | 29 | 8884 | 46.09 | 876 | 861 | 174.1 |
| B | 7 | 220 | 224386 | 1385.33 | 862 | 844 | 161.4 |
| B | 4 | 171 | 73149 | 448.09 | 862 | 844 | 161.4 |
| B | 3 | 64 | 20065 | 119.12 | 862 | 844 | 161.4 |
| C | 9 | 54 | 205511 | 1062.48 | 841 | 850 | 192.6 |
| C | 14 | 238 | 134256 | 692.57 | 841 | 850 | 192.6 |
| C | 3 | 233 | 35013 | 177.35 | 841 | 850 | 192.6 |
| D | 7 | 238 | 312049 | 1492.26 | 856 | 832 | 208.6 |
| D | 1 | 52 | 42467 | 199.64 | 856 | 832 | 208.6 |
| D | 2 | 234 | 27633 | 128.51 | 856 | 832 | 208.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
