| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_072T04_9000002794_18691cztM0_level2.evt | modeM0/AS1A05_072T04_9000002794_18691cztM0_level2_quad_clean.evt |
| Size (bytes) | 592,176,960 | 105,321,600 |
| Size | 564.7 MB | 100.4 MB |
| Events in quadrant A | 3,959,777 | 662,743 |
| Events in quadrant B | 4,123,166 | 675,674 |
| Events in quadrant C | 4,307,638 | 659,264 |
| Events in quadrant D | 4,996,645 | 631,486 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 168 | 0 |
| B | 0 | 168 | 0 |
| C | 0 | 168 | 0 |
| D | 0 | 168 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17147 | 3 |
| B | 0 | 17637 | 3 |
| C | 0 | 18104 | 3 |
| D | 0 | 20362 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8052 | 71 | 0.881769% |
| B | 8053 | 136 | 1.688812% |
| C | 8053 | 201 | 2.495964% |
| D | 8053 | 364 | 4.520055% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8858 | 8055 | 7 | 7 | 0.08% | 0.09% |  |
| B | 8859 | 8056 | 3 | 3 | 0.03% | 0.04% |  |
| C | 8859 | 8056 | 7 | 7 | 0.08% | 0.09% |  |
| D | 8859 | 8056 | 285 | 285 | 3.22% | 3.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 97690 | 487.94 | 990 | 968 | 198.2 |
| A | 9 | 143 | 36104 | 177.25 | 990 | 968 | 198.2 |
| A | 13 | 254 | 11465 | 52.95 | 990 | 968 | 198.2 |
| B | 7 | 220 | 90913 | 474.57 | 992 | 964 | 189.5 |
| B | 4 | 171 | 36967 | 189.95 | 992 | 964 | 189.5 |
| B | 0 | 230 | 25341 | 128.61 | 992 | 964 | 189.5 |
| C | 5 | 112 | 245620 | 1089.92 | 955 | 960 | 224.5 |
| C | 14 | 238 | 148363 | 656.66 | 955 | 960 | 224.5 |
| C | 9 | 54 | 91053 | 401.35 | 955 | 960 | 224.5 |
| D | 1 | 52 | 919194 | 3892.46 | 959 | 932 | 235.9 |
| D | 7 | 238 | 339240 | 1434.07 | 959 | 932 | 235.9 |
| D | 7 | 38 | 64747 | 270.51 | 959 | 932 | 235.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
