| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_072T04_9000002794_18700cztM0_level2.evt | modeM0/AS1A05_072T04_9000002794_18700cztM0_level2_quad_clean.evt |
| Size (bytes) | 598,688,640 | 76,389,120 |
| Size | 571.0 MB | 72.9 MB |
| Events in quadrant A | 4,157,526 | 472,056 |
| Events in quadrant B | 3,686,351 | 482,073 |
| Events in quadrant C | 3,638,746 | 466,797 |
| Events in quadrant D | 6,202,337 | 432,184 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16504 | 2 |
| B | 0 | 15018 | 2 |
| C | 0 | 14806 | 2 |
| D | 0 | 23020 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6594 | 256 | 3.882317% |
| B | 6594 | 119 | 1.804671% |
| C | 6594 | 135 | 2.047316% |
| D | 6594 | 592 | 8.977859% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7854 | 6594 | 91 | 91 | 1.16% | 1.38% |  |
| B | 7854 | 6595 | 5 | 5 | 0.06% | 0.08% |  |
| C | 7854 | 6595 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7854 | 6595 | 445 | 445 | 5.67% | 6.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 443700 | 2440.68 | 912 | 896 | 181.4 |
| A | 9 | 143 | 191565 | 1050.94 | 912 | 896 | 181.4 |
| A | 13 | 254 | 10799 | 54.58 | 912 | 896 | 181.4 |
| B | 7 | 220 | 67558 | 391.98 | 908 | 889 | 170.1 |
| B | 0 | 197 | 19330 | 108.42 | 908 | 889 | 170.1 |
| B | 12 | 111 | 19094 | 107.04 | 908 | 889 | 170.1 |
| C | 14 | 238 | 140680 | 694.08 | 878 | 886 | 201.4 |
| C | 9 | 54 | 52888 | 258.19 | 878 | 886 | 201.4 |
| C | 3 | 233 | 17561 | 82.79 | 878 | 886 | 201.4 |
| D | 7 | 238 | 1373810 | 6498.61 | 876 | 850 | 211.3 |
| D | 1 | 52 | 1149014 | 5434.59 | 876 | 850 | 211.3 |
| D | 12 | 110 | 325711 | 1537.66 | 876 | 850 | 211.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
