| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_072T04_9000002802_18732cztM0_level2.evt | modeM0/AS1A05_072T04_9000002802_18732cztM0_level2_quad_clean.evt |
| Size (bytes) | 495,601,920 | 80,916,480 |
| Size | 472.6 MB | 77.2 MB |
| Events in quadrant A | 3,292,836 | 502,640 |
| Events in quadrant B | 4,072,094 | 506,051 |
| Events in quadrant C | 3,430,647 | 495,522 |
| Events in quadrant D | 3,766,178 | 486,407 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13858 | 2 |
| B | 0 | 16364 | 2 |
| C | 0 | 14197 | 2 |
| D | 0 | 15458 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6591 | 72 | 1.092399% |
| B | 6591 | 200 | 3.034441% |
| C | 6591 | 117 | 1.775148% |
| D | 6591 | 131 | 1.987559% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7616 | 6592 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7616 | 6592 | 67 | 67 | 0.88% | 1.02% |  |
| C | 7616 | 6592 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7616 | 6592 | 55 | 55 | 0.72% | 0.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 29 | 11818 | 64.15 | 850 | 835 | 171.2 |
| A | 13 | 254 | 10750 | 57.91 | 850 | 835 | 171.2 |
| A | 0 | 226 | 7234 | 37.38 | 850 | 835 | 171.2 |
| B | 10 | 245 | 559872 | 3541.79 | 839 | 820 | 157.8 |
| B | 7 | 220 | 137197 | 864.0 | 839 | 820 | 157.8 |
| B | 10 | 247 | 23157 | 141.51 | 839 | 820 | 157.8 |
| C | 14 | 238 | 127811 | 666.06 | 819 | 825 | 190.7 |
| C | 3 | 233 | 96746 | 503.12 | 819 | 825 | 190.7 |
| C | 13 | 61 | 5646 | 25.29 | 819 | 825 | 190.7 |
| D | 14 | 34 | 372329 | 1852.51 | 829 | 805 | 200.6 |
| D | 10 | 70 | 113551 | 562.18 | 829 | 805 | 200.6 |
| D | 7 | 238 | 52817 | 259.34 | 829 | 805 | 200.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
