| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_156T01_9000002804_18744cztM0_level2.evt | modeM0/AS1A05_156T01_9000002804_18744cztM0_level2_quad_clean.evt |
| Size (bytes) | 187,704,000 | 21,015,360 |
| Size | 179.0 MB | 20.0 MB |
| Events in quadrant A | 1,425,192 | 116,726 |
| Events in quadrant B | 1,338,926 | 119,564 |
| Events in quadrant C | 1,323,899 | 115,873 |
| Events in quadrant D | 1,436,387 | 115,576 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5928 | 1 |
| B | 0 | 5430 | 1 |
| C | 0 | 5328 | 1 |
| D | 0 | 5833 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 48 | 0 |
| B | 0 | 48 | 0 |
| C | 0 | 48 | 0 |
| D | 0 | 48 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2331 | 87 | 3.732304% |
| B | 2331 | 86 | 3.689404% |
| C | 2330 | 86 | 3.690987% |
| D | 2330 | 73 | 3.133047% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3611 | 2332 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3611 | 2332 | 0 | 0 | 0.00% | 0.00% |  |
| C | 3610 | 2331 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3610 | 2331 | 8 | 8 | 0.22% | 0.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 191 | 100914 | 1449.92 | 340 | 334 | 69.4 |
| A | 11 | 29 | 7305 | 100.49 | 340 | 334 | 69.4 |
| A | 15 | 192 | 5794 | 78.71 | 340 | 334 | 69.4 |
| B | 12 | 111 | 7531 | 110.55 | 335 | 327 | 65.2 |
| B | 0 | 229 | 7462 | 109.49 | 335 | 327 | 65.2 |
| B | 0 | 190 | 7268 | 106.51 | 335 | 327 | 65.2 |
| C | 14 | 238 | 50005 | 657.77 | 322 | 324 | 75.5 |
| C | 3 | 233 | 17470 | 227.01 | 322 | 324 | 75.5 |
| C | 13 | 61 | 2309 | 26.28 | 322 | 324 | 75.5 |
| D | 13 | 168 | 87106 | 1058.99 | 332 | 322 | 81.9 |
| D | 7 | 38 | 68809 | 835.72 | 332 | 322 | 81.9 |
| D | 7 | 96 | 17374 | 208.08 | 332 | 322 | 81.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
